Sony CDP-CE245 - Power SW and Sensor Board Parts; Parts List

42
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
MAIN POWER SW SENSOR
Q307 8-729-029-66 TRANSISTOR DTC114ESA
Q352 8-729-029-56 TRANSISTOR DTA144ESA
Q353 8-729-029-56 TRANSISTOR DTA144ESA
Q356 8-729-029-56 TRANSISTOR DTA144ESA
Q402 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q405 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q502 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q505 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q601 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R301 1-249-429-11 CARBON 10K 5% 1/4W
R302 1-249-429-11 CARBON 10K 5% 1/4W
R306 1-249-429-11 CARBON 10K 5% 1/4W
R308 1-249-441-11 CARBON 100K 5% 1/4W
R313 1-249-429-11 CARBON 10K 5% 1/4W
R320 1-249-427-11 CARBON 6.8K 5% 1/4W
R321 1-249-427-11 CARBON 6.8K 5% 1/4W
R322 1-249-427-11 CARBON 6.8K 5% 1/4W
R323 1-249-427-11 CARBON 6.8K 5% 1/4W
R324 1-249-429-11 CARBON 10K 5% 1/4W
R325 1-249-417-11 CARBON 1K 5% 1/4W
R326 1-249-425-11 CARBON 4.7K 5% 1/4W
R327 1-249-425-11 CARBON 4.7K 5% 1/4W
R329 1-249-425-11 CARBON 4.7K 5% 1/4W
R352 1-249-441-11 CARBON 100K 5% 1/4W
R353 1-249-441-11 CARBON 100K 5% 1/4W
R356 1-249-441-11 CARBON 100K 5% 1/4W
R401 1-215-453-00 METAL 22K 1% 1/4W
R402 1-215-425-00 METAL 1.5K 1% 1/4W
R403 1-215-425-00 METAL 1.5K 1% 1/4W
R404 1-215-445-00 METAL 10K 1% 1/4W
R405 1-215-443-00 METAL 8.2K 1% 1/4W
R406 1-215-469-00 METAL 100K 1% 1/4W
R414 1-215-405-00 METAL 220 1% 1/4W
R415 1-215-405-00 METAL 220 1% 1/4W
R419 1-249-421-11 CARBON 2.2K 5% 1/4W
R420 1-215-405-00 METAL 220 1% 1/4W
R422 1-249-421-11 CARBON 2.2K 5% 1/4W
R501 1-215-453-00 METAL 22K 1% 1/4W
R502 1-215-425-00 METAL 1.5K 1% 1/4W
R503 1-215-425-00 METAL 1.5K 1% 1/4W
R504 1-215-445-00 METAL 10K 1% 1/4W
R505 1-215-443-00 METAL 8.2K 1% 1/4W
R506 1-215-469-00 METAL 100K 1% 1/4W
R514 1-215-405-00 METAL 220 1% 1/4W
R515 1-215-405-00 METAL 220 1% 1/4W
R519 1-249-421-11 CARBON 2.2K 5% 1/4W
R520 1-215-405-00 METAL 220 1% 1/4W
R522 1-249-421-11 CARBON 2.2K 5% 1/4W
R601 1-249-435-11 CARBON 33K 5% 1/4W
R602 1-249-429-11 CARBON 10K 5% 1/4W
R603 1-249-438-11 CARBON 56K 5% 1/4W
R604 1-249-429-11 CARBON 10K 5% 1/4W
R605 1-249-411-11 CARBON 330 5% 1/4W
R607 1-249-389-11 CARBON 4.7 5% 1/4W
< SWITCH >
0 S602 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR) (E, EA)
< VIBRATOR >
X301 1-579-175-11 VIBRATOR, CERAMIC (10MHz)
**************************************************************
1-676-540-11 POWER SW BOARD
*****************
< CAPACITOR >
0 C601 1-113-924-11 CERAMIC 0.0047uF 20% 250V
< CONNECTOR >
* CN601 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P
* CN602 1-568-226-11 PIN, CONNECTOR 2P
< SWITCH >
0 S601 1-572-267-51 SWITCH, PUSH (AC POWER) (1 KEY)
(POWER)
**************************************************************
1-676-245-11 SENSOR BOARD
**************
< CONNECTOR >
CN10 1-750-243-11 SOCKET, CONNECTOR 6P
< DIODE >
D10 8-749-924-18 PHOTO INTERRUPTER RPI-1391
D11 8-749-017-45 IC RPR-220CIN
< RESISTOR >
R10 1-249-416-11 CARBON 820 5% 1/4W
R11 1-249-407-11 CARBON 150 5% 1/4W
R12 1-249-429-11 CARBON 10K 5% 1/4W
**************************************************************
MISCELLANEOUS
**************
66 1-792-486-11 WIRE (FLAT TYPE) (37 CORE)
105 1-792-130-11 WIRE (FLAT TYPE) (21 CORE)
0 110 1-558-943-41 CORD, POWER (E)
0 110 1-575-651-21 CORD, POWER (AEP, UK, EA, SP)
0 110 1-590-926-11 CORD, POWER (CND)
0 110 1-696-845-11 CORD, POWER (AUS)
0 110 1-783-531-41 CORD, POWER (US)
0 111 1-569-008-31 ADAPTOR, CONVERSION (EA)
0 111 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
268 1-471-061-11 MAGNET ASSY
271 1-791-930-11 WIRE (FLAT TYPE) (6 CORE)
0 305 8-848-379-31 OPTICAL PICK-UP KSS-213BA/F-NP
306 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
M10 A-4672-879-A MOTOR ASSY, LOADING
M11 A-4672-867-A MOTOR ASSY, ROTARY (TRAY)
M101 X-4917-523-3 MOTOR ASSY (SPINDLE)
