1818
CDP-CE275/CE375
6-4. PRINTED WIRING BOARDS – JUNCTION/SENSOR/LOADING MOTOR Boards – • See page 15 for Circuit Boards Location.
(Page 20)
TO MAIN
BOARD
• Semiconductor
Location
Ref. No. Location
D10 B-4
D11 E-3
• Semiconductor
Location
Ref. No. Location
IC11 C-2
