Sony CDP-CE375 - Electrical Parts List; Component Identification and Listing

35
CDP-CE275/CE375
SECTION 8
ELECTRICAL PARTS LIST
BD
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4725-568-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C102 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C103 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C110 1-126-206-11 ELECT CHIP 100UF 20% 6.3V
C111 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C112 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C120 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C121 1-162-970-11 CERAMIC CHIP 0.01UF 10% 25V
C122 1-117-863-11 CERAMIC CHIP 0.47UF 10.00% 6.3V
C123 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C124 1-162-967-11 CERAMIC CHIP 0.0033UF 10% 50V
C125 1-162-965-11 CERAMIC CHIP 0.0015UF 10% 50V
C126 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C130 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C131 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C132 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C133 1-126-607-11 ELECT CHIP 47UF 20% 4V
C134 1-126-607-11 ELECT CHIP 47UF 20% 4V
C136 1-107-826-11 CERAMIC CHIP 0.1UF 10.00% 16V
C137 1-126-209-11 ELECT CHIP 100UF 20.00% 4V
C138 1-162-964-11 CERAMIC CHIP 0.001UF 10% 50V
C139 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C140 1-164-505-11 CERAMIC CHIP 2.2UF 16V
C145 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C150 1-126-204-11 ELECT CHIP 47UF 20% 16V
C151 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C152 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C153 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C154 1-162-964-11 CERAMIC CHIP 0.001UF 10% 50V
C158 1-164-172-11 CERAMIC CHIP 0.0056UF 10.00% 25V
C171 1-126-206-11 ELECT CHIP 100UF 20% 6.3V
C172 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C173 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C174 1-115-412-11 CERAMIC CHIP 680PF 5.00% 25V
C181 1-126-206-11 ELECT CHIP 100UF 20% 6.3V
C182 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C183 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C184 1-115-412-11 CERAMIC CHIP 680PF 5.00% 25V
C191 1-126-205-11 ELECT CHIP 47UF 20% 6.3V
C192 1-164-156-11 CERAMIC CHIP 0.1UF 25V
C193 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C194 1-162-918-11 CERAMIC CHIP 18PF 5.00% 50V
C199 1-164-156-11 CERAMIC CHIP 0.1UF 25V
< CONNECTOR >
CN101 1-784-360-11 CONNECTOR,FFC(LIF(NON-ZIF))21P
CN102 1-777-937-11 CONNECTOR, FFC/FPC 16P
< FERRITE BEAD >
FB191 1-216-864-91 SHORT 0
< IC >
IC101 8-752-386-85 IC CXD2587Q
IC131 8-752-089-74 IC CXA2581N-T4
IC150 8-759-829-14 IC AN4800SB
< MOTOR >
M101 X-4917-523-3 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
< TRANSISTOR >
Q131 8-729-010-08 TRANSISTOR MSB710-R
Q132 8-729-600-22 TRANSISTOR 2SA1235-F
< RESISTOR >
R101 1-216-835-11 METAL CHIP 15K 5% 1/16W
R102 1-216-845-11 METAL CHIP 100K 5% 1/16W
R103 1-216-835-11 METAL CHIP 15K 5% 1/16W
R110 1-216-821-11 METAL CHIP 1K 5% 1/16W
R111 1-216-809-11 METAL CHIP 100 5% 1/16W
R112 1-216-833-11 METAL CHIP 10K 5% 1/16W
R120 1-216-839-11 METAL CHIP 33K 5% 1/16W
R121 1-216-833-11 METAL CHIP 10K 5% 1/16W
R122 1-216-845-11 METAL CHIP 100K 5% 1/16W
R123 1-216-857-11 METAL CHIP 1M 5% 1/16W
R125 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R126 1-216-833-11 METAL CHIP 10K 5% 1/16W
R127 1-216-821-11 METAL CHIP 1K 5% 1/16W
R129 1-216-815-11 METAL CHIP 330 5% 1/16W
R134 1-216-853-11 METAL CHIP 470K 5% 1/16W
R135 1-216-836-11 METAL CHIP 18K 5% 1/16W
R136 1-216-836-11 METAL CHIP 18K 5% 1/16W
R137 1-216-797-11 METAL CHIP 10 5% 1/16W
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
• Abbreviation
AUS : Australian model
CND : Canadian model
EA : Saudi Arabia model
SP : Singapore model
