Sony CDP-CE375 - 3 Disassembly

5
CDP-CE275/CE375
3-1. CASE
Note: Follow the disassembly procedure in the numerical order given.
SECTION 3
DISASSEMBLY
• The equipment can be removed using the following procedure.
Set Case Front Panel Assy
Base Unit (BU-5BD27) Optical Pick-up
Tray, Table Assy
CD Mechanism Block
Sensor Board
Jnuction Board, Loading Motor Board
3 two screws
(BVTP 3x8)
4 case
5
6
2
two screws
(case 3TP2)
1 two screws
(case 3TP2)
7 panel, loading
