37
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
CDP-CE275/CE375
KEY MAIN
1-681-140-11 KEY BOARD (CE275,CE375:US/CND)
*****************************
1-681-140-21 KEY BOARD (CE375:AUS/AEP/UK/SP/E)
********************************
< CAPACITOR >
C851 1-104-665-11 ELECT 100UF 20.00% 10V
< CONNECTOR >
CN812 1-750-185-11 CONNECTOR, BOARD TO BOARD 4P
< RESISTOR >
R824 1-249-415-11 CARBON 680 5% 1/4W F
R825 1-249-417-11 CARBON 1K 5% 1/4W F
R826 1-249-419-11 CARBON 1.5K 5% 1/4W F
R827 1-249-421-11 CARBON 2.2K 5% 1/4W F
R830 1-249-415-11 CARBON 680 5% 1/4W F
R831 1-249-417-11 CARBON 1K 5% 1/4W F
R832 1-249-419-11 CARBON 1.5K 5% 1/4W F
R833 1-249-421-11 CARBON 2.2K 5% 1/4W F
< SWITCH >
S812 1-771-349-21 SWITCH, KEYBOARD (DISC 5)
S812 1-771-349-41 SWITCH, KEYBOARD (DISC 5)
S813 1-771-349-21 SWITCH, KEYBOARD (DISC 4)
S813 1-771-349-41 SWITCH, KEYBOARD (DISC 4)
S814 1-771-349-21 SWITCH, KEYBOARD (DISC 3)
S814 1-771-349-41 SWITCH, KEYBOARD (DISC 3)
S815 1-771-349-21 SWITCH, KEYBOARD (DISC 2)
S815 1-771-349-41 SWITCH, KEYBOARD (DISC 2)
S816 1-771-349-21 SWITCH, KEYBOARD (DISC 1)
S816 1-771-349-41 SWITCH, KEYBOARD (DISC 1)
S817 1-771-349-21 SWITCH, KEYBOARD (TIMER)
S817 1-771-349-41 SWITCH, KEYBOARD (TIMER)
S818 1-771-349-21 SWITCH, KEYBOARD (REPEAT)
S818 1-771-349-41 SWITCH, KEYBOARD (REPEAT)
S819 1-771-349-21 SWITCH, KEYBOARD (FADER)
S819 1-771-349-41 SWITCH, KEYBOARD (FADER)
S820 1-771-349-21 SWITCH, KEYBOARD (P.SEARCH)
S820 1-771-349-41 SWITCH, KEYBOARD (P.SEARCH)
S821 1-771-349-21 SWITCH, KEYBOARD (PLAY MODE)
S821 1-771-349-41 SWITCH, KEYBOARD (PLAY MODE)
**************************************************************
A-4725-570-A MAIN BOARD, COMPLETE (CE275)
*********************
A-4725-571-A MAIN BOARD, COMPLETE (CE375:US/CND)
*********************
A-4725-579-A MAIN BOARD, COMPLETE
(CE375:AUS/AEP/UK/SP)
*********************
A-4725-581-A MAIN BOARD, COMPLETE (CE375:E)
*********************
7-685-871-01 SCREW +BVTT 3X6 (S)
< CAPACITOR >
C301 1-161-494-00 CERAMIC 0.022UF 25V
C302 1-104-665-11 ELECT 100UF 20.00% 10V
C303 1-161-494-00 CERAMIC 0.022UF 25V
C304 1-164-159-11 CERAMIC 0.1UF 50V
C325 1-161-494-00 CERAMIC 0.022UF 25V
C326 1-104-665-11 ELECT 100UF 20.00% 10V
C351 1-126-963-11 ELECT 4.7UF 20.00% 50V
C401 1-126-965-11 ELECT 22UF 20.00% 50V
C404 1-126-965-11 ELECT 22UF 20.00% 50V
C407 1-162-290-31 CERAMIC 470PF 10% 50V
C451 1-126-933-11 ELECT 100UF 20.00% 16V
(CE375)
C501 1-126-965-11 ELECT 22UF 20.00% 50V
C504 1-126-965-11 ELECT 22UF 20.00% 50V
C507 1-162-290-31 CERAMIC 470PF 10% 50V
C551 1-126-933-11 ELECT 100UF 20.00% 16V
(CE375)
C602 1-126-937-11 ELECT 4700UF 20.00% 16V
C603 1-126-767-11 ELECT 1000UF 20.00% 16V
C608 1-126-934-11 ELECT 220UF 20.00% 10V
C609 1-128-552-51 ELECT 47UF 20.00% 63V
C610 1-126-964-11 ELECT 10UF 20.00% 50V
C611 1-126-767-11 ELECT 1000UF 20.00% 16V
C613 1-126-935-11 ELECT 470UF 20.00% 6.3V
C616 1-161-494-00 CERAMIC 0.022UF 25V
C619 1-104-665-11 ELECT 100UF 20.00% 10V
0 C620 1-113-924-11 CERAMIC 0.0047UF 20.00% 250V
C622 1-164-159-11 CERAMIC 0.1UF 50V
< CONNECTOR >
CN301 1-784-798-11 CONNECTOR, FFC 37P
CN302 1-568-838-11 CONNECTOR, FFC 21P
CN311 1-573-911-11 PIN, CONNECTOR 13P
CN351 1-506-468-11 PIN, CONNECTOR 3P (CE375)
CN603 1-792-131-11 LEAD (WITH CONNECTOR)
< DIODE >
D353 8-719-991-33 DIODE 1SS133T-77
D601 8-719-024-99 DIODE 11ES2-NTA2B
D602 8-719-024-99 DIODE 11ES2-NTA2B
D603 8-719-024-99 DIODE 11ES2-NTA2B
D604 8-719-024-99 DIODE 11ES2-NTA2B
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
