Sony CDP-CE375 - Page 38

38
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
CDP-CE275/CE375
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
MAIN
D605 8-719-024-99 DIODE 11ES2-NTA2B
D606 8-719-110-08 DIODE RD8.2ESB2
D607 8-719-991-33 DIODE 1SS133T-77
D608 8-719-109-85 DIODE RD5.1ESB2
D609 8-719-991-33 DIODE 1SS133T-77
D610 8-719-983-79 DIODE MTZJ-T-72-27D
< GROUND TERMINAL BOARD >
EB601 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC301 8-752-919-66 IC CXP82532-013Q
IC303 8-749-921-12 IC GP1F32T
IC350 8-759-145-58 IC BA4558
IC351 8-759-167-88 IC NJM4565D (CE375)
IC601 8-759-039-69 IC UPC7805AHF
IC602 8-749-011-78 IC BA17807T
IC603 8-759-165-82 IC PST600E-T
< JACK >
J301 1-785-868-11 JACK, PIN 2P
< COIL >
L601 1-412-473-21 INDUCTOR 0UH
L602 1-414-151-21 INDUCTOR 470UH
< TRANSISTOR >
Q301 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q307 8-729-029-56 TRANSISTOR DTA144ESA-TP
Q352 8-729-029-56 TRANSISTOR DTA144ESA-TP
Q353 8-729-029-56 TRANSISTOR DTA144ESA-TP
Q356 8-729-029-56 TRANSISTOR DTA144ESA-TP
Q402 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q405 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q502 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q505 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q601 8-729-140-97 TRANSISTOR 2SB734-34
< RESISTOR >
R301 1-249-429-11 CARBON 10K 5% 1/4W
R302 1-249-429-11 CARBON 10K 5% 1/4W
R304 1-249-429-11 CARBON 10K 5% 1/4W
R305 1-247-807-31 CARBON 100 5% 1/4W
R306 1-249-429-11 CARBON 10K 5% 1/4W
R307 1-247-807-31 CARBON 100 5% 1/4W
R308 1-249-441-11 CARBON 100K 5% 1/4W
R320 1-249-427-11 CARBON 6.8K 5% 1/4W F
R321 1-249-427-11 CARBON 6.8K 5% 1/4W F
R322 1-249-427-11 CARBON 6.8K 5% 1/4W F
R323 1-249-427-11 CARBON 6.8K 5% 1/4W F
R324 1-249-429-11 CARBON 10K 5% 1/4W
R325 1-249-417-11 CARBON 1K 5% 1/4W F
R326 1-249-425-11 CARBON 4.7K 5% 1/4W F
R327 1-249-425-11 CARBON 4.7K 5% 1/4W F
R329 1-249-425-11 CARBON 4.7K 5% 1/4W F
R350 1-247-807-31 CARBON 100 5% 1/4W
R351 1-247-807-31 CARBON 100 5% 1/4W
R352 1-249-441-11 CARBON 100K 5% 1/4W
R353 1-249-441-11 CARBON 100K 5% 1/4W
R356 1-249-441-11 CARBON 100K 5% 1/4W
R401 1-247-895-00 CARBON 470K 5% 1/4W
R402 1-249-419-11 CARBON 1.5K 5% 1/4W F
R403 1-249-419-11 CARBON 1.5K 5% 1/4W F
R404 1-249-429-11 CARBON 10K 5% 1/4W
R405 1-249-429-11 CARBON 10K 5% 1/4W
R406 1-247-895-00 CARBON 470K 5% 1/4W
R414 1-249-409-11 CARBON 220 5% 1/4W F
R415 1-249-409-11 CARBON 220 5% 1/4W F
R419 1-249-421-11 CARBON 2.2K 5% 1/4W F
R420 1-249-409-11 CARBON 220 5% 1/4W F
R422 1-249-421-11 CARBON 2.2K 5% 1/4W F
R451 1-247-843-11 CARBON 3.3K 5% 1/4W
(CE375)
R452 1-249-429-11 CARBON 10K 5% 1/4W
(CE375)
R501 1-247-895-00 CARBON 470K 5% 1/4W
R502 1-249-419-11 CARBON 1.5K 5% 1/4W F
R503 1-249-419-11 CARBON 1.5K 5% 1/4W F
R504 1-249-429-11 CARBON 10K 5% 1/4W
R505 1-249-429-11 CARBON 10K 5% 1/4W
R506 1-247-895-00 CARBON 470K 5% 1/4W
R514 1-249-409-11 CARBON 220 5% 1/4W F
R515 1-249-409-11 CARBON 220 5% 1/4W F
R519 1-249-421-11 CARBON 2.2K 5% 1/4W F
R520 1-249-409-11 CARBON 220 5% 1/4W F
R522 1-249-421-11 CARBON 2.2K 5% 1/4W F
R551 1-247-843-11 CARBON 3.3K 5% 1/4W
(CE375)
R552 1-249-429-11 CARBON 10K 5% 1/4W
(CE375)
R601 1-249-429-11 CARBON 10K 5% 1/4W
R602 1-249-429-11 CARBON 10K 5% 1/4W
R603 1-249-429-11 CARBON 10K 5% 1/4W
R604 1-249-429-11 CARBON 10K 5% 1/4W
R605 1-249-411-11 CARBON 330 5% 1/4W
R606 1-247-807-31 CARBON 100 5% 1/4W
R607 1-249-389-11 CARBON 4.7 5% 1/4W F
< SWITCH >
S602 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR)(CE375:E)
< TRANSFORMER >
0 T601 1-435-342-11 TRANSFORMER, POWER
(CE275:US/CND,CE375:US/CND)
0 T601 1-435-343-11 TRANSFORMER, POWER
(CE275:AUS,CE375:AUS/AEP/UK/SP)
0 T601 1-435-344-11 TRANSFORMER, POWER (CE375:E)
< VIBRATOR >
X301 1-579-175-11 VIBRATOR, CERAMIC
**************************************************************
