39
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
CDP-CE275/CE375
1-681-141-11 POWER SW BOARD (CE275,CE375:US/CND)
****************
1-681-141-21 POWER SW BOARD
(CE375:AUS/AEP/UK/SP/E)
****************
< CAPACITOR >
0 C601 1-113-924-11 CERAMIC 0.0047UF 20.00% 250V
< CONNECTOR >
* CN601 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P
* CN602 1-568-226-11 PIN, CONNECTOR 2P
< SWITCH >
0 S601 1-762-581-11 SWITCH, AC POWER PUSH (1 KEY)
**************************************************************
1-676-244-11 LOADING MOTOR BOARD
*********************
**************************************************************
1-676-245-11 SENSOR BOARD
**************
1-676-246-11 JUNCTION BOARD
***************
< CAPACITOR >
C10 1-124-589-11 ELECT 47UF 20% 16V
C11 1-161-494-00 CERAMIC 0.022UF 25V
< CONNECTOR >
CN10 1-750-243-11 SOCKET, CONNECTOR 6P
CN11 1-573-911-11 PIN, CONNECTOR 13P
CN13 1-506-481-11 PIN, CONNECTOR 2P
* CN14 1-568-941-11 PIN, CONNECTOR 3P
CN15 1-784-767-11 CONNECTOR, FFC 6P
< DIODE >
D10 8-749-924-18 PHOTO INTERRUPTER RPI-1391
D11 8-749-017-45 SENSOR, PHONT RPR-220C1N
< IC >
IC11 8-759-356-03 IC BA6780
< RESISTOR >
R10 1-249-416-11 CARBON 820 5% 1/4W F
R11 1-249-407-11 CARBON 150 5% 1/4W F
R12 1-249-429-11 CARBON 10K 5% 1/4W
R21 1-249-429-11 CARBON 10K 5% 1/4W
R22 1-249-426-11 CARBON 5.6K 5% 1/4W
R23 1-249-425-11 CARBON 4.7K 5% 1/4W F
R24 1-249-430-11 CARBON 12K 5% 1/4W
R25 1-249-382-11 CARBON 1.2 5% 1/6W F
R26 1-249-382-11 CARBON 1.2 5% 1/6W F
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
< SWITCH >
S11 1-771-836-11 SWITCH, LEVER (SLIDE)
**************************************************************
MISCELLANEOUS
***************
0 9 1-575-651-21 CORD, POWER (CE375:AEP/UK/SP)
0 9 1-696-845-11 CORD, POWER (CE275:AUS,CE375:AUS)
0 9 1-777-071-41 CORD, POWER (CE375:AEP/UK/SP)
0 9 1-783-528-21 CORD, POWER (TRACKING)(CE375:E)
0 9 1-783-531-31 CORD, POWER
(CE275:US/CND,CE375US/CND)
0 T601 1-435-342-11 TRANSFORMER, POWER
(CE275:US/CND,CE375:US/CND)
0 T601 1-435-343-11 TRANSFORMER, POWER
(CE275:AUS,CE375:AUS/AEP/UK/SP)
0 T601 1-435-344-11 TRANSFORMER, POWER (CE375:E)
60 1-792-486-11 WIRE (FLAT TYPE)(37 CORE)
FL801 1-517-946-21 INDICATOR TUBE, FLUORESCENT
111 1-791-930-11 WIRE (FLAT TYPE)(6 CORE)
116 1-757-648-11 WIRE (FLAT TYPE)(21 CORE)
160 1-418-746-11 ENCODER, ROTARY
0 201 1-796-033-11 LIGHT PICK UP (PXR-104X)
202 1-782-817-11 WIRE (FLAT TYPE)(16 CORE)
**************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-418-857-11 COMMANDER, STANDARD (RM-DC345)
(CE375:AUS/AEP/UK/SP/E)
1-476-132-11 REMOTE COMMANDER (RM-DC355)
(CE375:US/CND)
1-558-271-11 CORD, CONNECTION
4-233-300-11 MANUAL, INSTRUCTION (ENGLISH)
(CE275:US,CE375:US)
4-233-300-21 MANUAL, INSTRUCTION (ENGLISH, FRENCH)
(CE275:CND,CE375:CND)
4-233-300-31 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
GERMAN, SPANISH, DUTCH, SWEDISH,
ITALIAN, PORTUGUESE) (CE375:AEP)
4-233-300-51 MANUAL, INSTRUCTION
(ENGLISH, FINNISH, PORTUGUESE, RUSSIAN)
(CE375:SP,CE375:E)
4-233-300-61 MANUAL, INSTRUCTION (ENGLISH)
(CE275:AUS,CE375:AUS/UK)
4-234-873-01 COVER, BATTERY(RM-DC345)
(CE375:AUS/AEP/UK/SP/E)
4-981-643-01 COVER, BATTERY(RM-DC355)
(CE375:US/CND)
POWER SW
SENSOR JUNCTION
LOADING MOTOR
