– 36 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BD
R120 1-216-089-91 RES, CHIP 47K 5% 1/10W
R121 1-216-114-00 RES, CHIP 510K 5% 1/10W
R122 1-216-097-91 RES, CHIP 100K 5% 1/10W
R123 1-216-099-00 METAL CHIP 120K 5% 1/10W
R124 1-216-091-00 METAL CHIP 56K 5% 1/10W
R125 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R126 1-216-063-91 RES, CHIP 3.9K 5% 1/10W
R127 1-216-089-91 RES, CHIP 47K 5% 1/10W
R128 1-216-098-00 METAL CHIP 110K 5% 1/10W
R129 1-216-049-91 RES, CHIP 1K 5% 1/10W
R130 1-216-079-00 METAL CHIP 18K 5% 1/10W
R131 1-216-079-00 METAL CHIP 18K 5% 1/10W
R132 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R133 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R134 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R135 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R136 1-216-073-00 METAL CHIP 10K 5% 1/10W
R137 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R138 1-216-025-91 RES, CHIP 100 5% 1/10W
R156 1-216-081-00 METAL CHIP 22K 5% 1/10W
R157 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R158 1-216-001-00 METAL CHIP 10 5% 1/10W
R159 1-216-121-91 RES, CHIP 1M 5% 1/10W
R161 1-216-097-91 RES, CHIP 100K 5% 1/10W
R162 1-216-073-00 METAL CHIP 10K 5% 1/10W
R163 1-216-121-91 RES, CHIP 1M 5% 1/10W
R164 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R165 1-216-049-91 RES, CHIP 1K 5% 1/10W
R166 1-216-073-00 METAL CHIP 10K 5% 1/10W
R167 1-216-081-00 METAL CHIP 22K 5% 1/10W
R168 1-216-073-00 METAL CHIP 10K 5% 1/10W
R169 1-216-079-00 METAL CHIP 18K 5% 1/10W
R170 1-216-081-00 METAL CHIP 22K 5% 1/10W
R171 1-216-073-00 METAL CHIP 10K 5% 1/10W
R172 1-216-079-00 METAL CHIP 18K 5% 1/10W
R173 1-216-049-91 RES, CHIP 1K 5% 1/10W
R174 1-216-033-00 METAL CHIP 220 5% 1/10W
R175 1-216-025-91 RES, CHIP 100 5% 1/10W
R176 1-216-049-91 RES, CHIP 1K 5% 1/10W
R177 1-216-049-91 RES, CHIP 1K 5% 1/10W
R178 1-216-049-91 RES, CHIP 1K 5% 1/10W
R179 1-216-025-91 RES, CHIP 100 5% 1/10W
R180 1-216-025-91 RES, CHIP 100 5% 1/10W
R181 1-216-025-91 RES, CHIP 100 5% 1/10W
R182 1-216-025-91 RES, CHIP 100 5% 1/10W
R183 1-216-025-91 RES, CHIP 100 5% 1/10W
R188 1-216-037-00 METAL CHIP 330 5% 1/10W
R189 1-216-025-91 RES, CHIP 100 5% 1/10W
R190 1-216-097-91 RES, CHIP 100K 5% 1/10W
R191 1-216-105-91 RES, CHIP 220K 5% 1/10W
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X101 1-767-408-21 VIBRATOR, CRYSTAL (16.9344MHz)
************************************************************
* 1-645-721-11 LOADING BOARD
**************
< CONNECTOR >
* CN151 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S151 1-572-086-11 SWITCH, LEAF (LOAD OUT)
S152 1-572-086-11 SWITCH, LEAF (LOAD IN)
**************************************************************
* A-4699-941-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C301 1-162-286-21 CERAMIC 220PF 10% 50V
C302 1-130-479-00 MYLAR 0.0047uF 5% 50V
C303 1-126-967-11 ELECT 47uF 20% 16V
C304 1-162-286-21 CERAMIC 220PF 10% 50V
C305 1-130-472-00 MYLAR 0.0012uF 5% 50V
C306 1-161-494-00 CERAMIC 0.022uF 25V
C307 1-162-290-31 CERAMIC 470PF 10% 50V
C308 1-104-666-11 ELECT 220uF 20% 25V
C309 1-161-494-00 CERAMIC 0.022uF 25V
C310 1-164-159-21 CERAMIC 0.1uF 50V
C351 1-162-286-21 CERAMIC 220PF 10% 50V
C352 1-130-479-00 MYLAR 0.0047uF 5% 50V
C353 1-126-967-11 ELECT 47uF 20% 16V
C354 1-162-286-21 CERAMIC 220PF 10% 50V
C355 1-130-472-00 MYLAR 0.0012uF 5% 50V
C356 1-161-494-00 CERAMIC 0.022uF 25V
C357 1-162-290-31 CERAMIC 470PF 10% 50V
C401 1-161-494-00 CERAMIC 0.022uF 25V
C402 1-162-306-11 CERAMIC 0.01uF 20% 16V
C403 1-126-964-11 ELECT 10uF 20% 50V
C702 1-126-964-11 ELECT 10uF 20% 50V
C703 1-162-294-31 CERAMIC 0.001uF 10% 50V
C704 1-104-666-11 ELECT 220uF 20% 25V
C705 1-126-964-11 ELECT 10uF 20% 50V
C706 1-126-933-11 ELECT 100uF 20% 16V
C707 1-126-960-11 ELECT 1uF 20% 50V
C708 1-126-964-11 ELECT 10uF 20% 50V
C709 1-126-964-11 ELECT 10uF 20% 50V
C710 1-126-964-11 ELECT 10uF 20% 50V
C711 1-126-956-91 ELECT 0.1uF 20% 50V
C713 1-164-159-21 CERAMIC 0.1uF 50V
C714 1-164-159-21 CERAMIC 0.1uF 50V
C715 1-126-933-11 ELECT 100uF 20% 16V
C716 1-162-290-31 CERAMIC 470PF 10% 50V
C717 1-162-290-31 CERAMIC 470PF 10% 50V
C718 1-164-159-21 CERAMIC 0.1uF 50V
C719 1-164-159-21 CERAMIC 0.1uF 50V
C901 1-126-939-11 ELECT 10000uF 20% 16V
C902 1-126-768-11 ELECT 2200uF 20% 16V
C903 1-128-576-11 ELECT 100uF 20% 63V
C904 1-164-159-21 CERAMIC 0.1uF 50V
