– 37 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C905 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
CN401 1-750-426-11 CONNECTOR, FFC/FPC 21P
CN402 1-750-426-11 CONNECTOR, FFC/FPC 21P
CN601 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-109-97 DIODE RD6.8ES-B2
D403 8-719-921-40 DIODE MTZJ-4.7C
D404 8-719-982-19 DIODE MTZJ-30A
D701 8-719-991-33 DIODE 1SS133T-77
D702 8-719-991-33 DIODE 1SS133T-77
D703 8-719-991-33 DIODE 1SS133T-77
D704 8-719-991-33 DIODE 1SS133T-77
D705 8-719-991-33 DIODE 1SS133T-77
D706 8-719-991-33 DIODE 1SS133T-77
D901 8-719-200-82 DIODE 11ES2
D902 8-719-200-82 DIODE 11ES2
D903 8-719-200-82 DIODE 11ES2
D904 8-719-200-82 DIODE 11ES2
D905 8-719-200-82 DIODE 11ES2
< IC >
IC301 8-759-634-51 IC M5218AP
IC302 8-759-634-51 IC M5218AP
IC303 8-749-921-12 IC GP1F32T (DIGITAL OUT OPTICAL)
IC401 8-759-822-09 IC LB1641
IC701 8-759-821-93 IC LA5601
< JACK >
J401 1-770-719-11 JACK, PIN 2P (LINE OUT)
< COIL >
L701 1-414-223-11 INDUCTOR 470uH
L703 1-410-507-11 INDUCTOR 6.8uH
L704 1-410-322-11 INDUCTOR 3.3uH
< TRANSISTOR >
Q302 8-729-922-37 TRANSISTOR 2SD2144S-UVW
Q303 8-729-922-37 TRANSISTOR 2SD2144S-UVW
Q304 8-729-029-56 TRANSISTOR DTA144ESA
Q352 8-729-922-37 TRANSISTOR 2SD2144S-UVW
Q353 8-729-922-37 TRANSISTOR 2SD2144S-UVW
Q354 8-729-029-56 TRANSISTOR DTA144ESA
Q401 8-729-041-38 TRANSISTOR 2SB1241TV2Q
Q402 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q701 8-729-029-56 TRANSISTOR DTA144ESA
< RESISTOR >
R301 1-247-848-11 CARBON 5.1K 5% 1/4W
R302 1-249-429-11 CARBON 10K 5% 1/4W
R303 1-249-432-11 CARBON 18K 5% 1/4W
R304 1-249-420-11 CARBON 1.8K 5% 1/4W F
R305 1-249-420-11 CARBON 1.8K 5% 1/4W F
R307 1-249-432-11 CARBON 18K 5% 1/4W
R308 1-247-891-00 CARBON 330K 5% 1/4W
R310 1-247-807-31 CARBON 100 5% 1/4W
R311 1-249-429-11 CARBON 10K 5% 1/4W
R312 1-249-429-11 CARBON 10K 5% 1/4W
R313 1-249-413-11 CARBON 470 5% 1/4W F
R314 1-249-421-11 CARBON 2.2K 5% 1/4W F
R315 1-249-413-11 CARBON 470 5% 1/4W F
R316 1-249-421-11 CARBON 2.2K 5% 1/4W F
R318 1-249-441-11 CARBON 100K 5% 1/4W
R320 1-247-807-31 CARBON 100 5% 1/4W
R351 1-247-848-11 CARBON 5.1K 5% 1/4W
R352 1-249-429-11 CARBON 10K 5% 1/4W
R353 1-249-432-11 CARBON 18K 5% 1/4W
R354 1-249-420-11 CARBON 1.8K 5% 1/4W F
R355 1-249-420-11 CARBON 1.8K 5% 1/4W F
R357 1-249-432-11 CARBON 18K 5% 1/4W
R358 1-247-891-00 CARBON 330K 5% 1/4W
R360 1-247-807-31 CARBON 100 5% 1/4W
R361 1-249-429-11 CARBON 10K 5% 1/4W
R362 1-249-429-11 CARBON 10K 5% 1/4W
R363 1-249-413-11 CARBON 470 5% 1/4W F
R364 1-249-421-11 CARBON 2.2K 5% 1/4W F
R365 1-249-413-11 CARBON 470 5% 1/4W F
R366 1-249-421-11 CARBON 2.2K 5% 1/4W F
R368 1-249-441-11 CARBON 100K 5% 1/4W
R370 1-247-807-31 CARBON 100 5% 1/4W
R401 1-249-432-11 CARBON 18K 5% 1/4W
R402 1-249-441-11 CARBON 100K 5% 1/4W
R403 1-249-425-11 CARBON 4.7K 5% 1/4W F
R404 1-249-441-11 CARBON 100K 5% 1/4W
R405 1-249-432-11 CARBON 18K 5% 1/4W
R406 1-249-427-11 CARBON 6.8K 5% 1/4W F
R407 1-249-432-11 CARBON 18K 5% 1/4W
R408 1-249-427-11 CARBON 6.8K 5% 1/4W F
R701 1-249-419-11 CARBON 1.5K 5% 1/4W F
R702 1-249-441-11 CARBON 100K 5% 1/4W
R704 1-247-807-31 CARBON 100 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W F
R706 1-247-807-31 CARBON 100 5% 1/4W
R707 1-247-807-31 CARBON 100 5% 1/4W
R708 1-247-807-31 CARBON 100 5% 1/4W
R709 1-247-807-31 CARBON 100 5% 1/4W
< TRANSFORMER >
! T901 1-423-979-11 TRANSFORMER, POWER
**************************************************************
* A-4699-942-A PANEL BOARD, COMPLETE
**********************
< CAPACITOR >
C501 1-161-494-00 CERAMIC 0.022uF 25V
C502 1-161-494-00 CERAMIC 0.022uF 25V
C503 1-164-159-21 CERAMIC 0.1uF 50V
C504 1-164-159-21 CERAMIC 0.1uF 50V
C506 1-124-584-00 ELECT 100uF 20% 10V
PANEL
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number
specified.
