– 38 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
PANEL
POWER SW
< CONNECTOR >
* CN501 1-568-864-11 SOCKET, CONNECTOR 21P
< FLUORESCENT INDICATOR >
FL501 1-517-297-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC501 8-752-880-56 IC CXP82616-034Q
IC502 8-749-014-66 IC NJL56H400
< TRANSISTOR >
Q501 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R501 1-249-427-11 CARBON 6.8K 5% 1/4W F
R502 1-249-427-11 CARBON 6.8K 5% 1/4W F
R503 1-249-427-11 CARBON 6.8K 5% 1/4W F
R504 1-249-415-11 CARBON 680 5% 1/4W F
R505 1-249-417-11 CARBON 1K 5% 1/4W F
R506 1-249-417-11 CARBON 1K 5% 1/4W F
R507 1-249-419-11 CARBON 1.5K 5% 1/4W F
R508 1-249-421-11 CARBON 2.2K 5% 1/4W F
R509 1-249-427-11 CARBON 6.8K 5% 1/4W F
R510 1-249-415-11 CARBON 680 5% 1/4W F
R511 1-249-417-11 CARBON 1K 5% 1/4W F
R512 1-249-419-11 CARBON 1.5K 5% 1/4W F
R513 1-249-427-11 CARBON 6.8K 5% 1/4W F
R514 1-249-415-11 CARBON 680 5% 1/4W F
R515 1-247-807-31 CARBON 100 5% 1/4W
R516 1-249-441-11 CARBON 100K 5% 1/4W
R517 1-247-843-11 CARBON 3.3K 5% 1/4W
R518 1-249-427-11 CARBON 6.8K 5% 1/4W F
R519 1-249-431-11 CARBON 15K 5% 1/4W
R520 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S502 1-554-303-21 SWITCH, TACTILE (TIME)
S503 1-554-303-21 SWITCH, TACTILE (REPEAT)
S504 1-554-303-21 SWITCH, TACTILE (PLAY MODE)
S508 1-554-303-21 SWITCH, TACTILE (PEAK SEARCH)
S509 1-554-303-21 SWITCH, TACTILE (CHECK)
S510 1-554-303-21 SWITCH, TACTILE (CLEAR)
S511 1-554-303-21 SWITCH, TACTILE (§ OPEN/CLOSE)
S512 1-554-303-21 SWITCH, TACTILE (·)
S513 1-554-303-21 SWITCH, TACTILE (P)
S514 1-554-303-21 SWITCH, TACTILE (p)
S515 1-554-303-21 SWITCH, TACTILE ())
S516 1-554-303-21 SWITCH, TACTILE (0)
S520 1-475-543-11 ENCODER, ROTARY (l AMS ±)
< VIBRATOR >
X501 1-577-082-11 VIBRATOR, CERAMIC (4MHz)
**************************************************************
* 1-668-618-11 POWER SW BOARD
****************
< SWITCH >
S501 1-554-118-00 SWITCH, PUSH (1 KEY)(1/u)
**************************************************************
MISCELLANEOUS
*************
11 1-590-243-11 WIRE (FLAT TYPE) (21 CORE)
!15 1-575-651-21 CORD, POWER
!21 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
* 101 1-452-538-11 MAGNET
116 1-452-925-21 MAGNET ASSY
!151 8-848-379-31 OPTICAL PICK-UP KSS-213BA/F-NP
152 1-769-069-11 WIRE (FLAT TYPE)(16 CORE)
M101 X-4917-523-4 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M151 A-4672-207-A MOTOR (L) ASSY (LOADING)
!T901 1-423-979-11 TRANSFORMER, POWER
**************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-467-880-11 REMOTE COMMANDER (RM-D420)(XE320)
1-558-271-11 CORD, CONNECTION (AUDIO 108cm)
3-861-618-11 MANUAL, INSTRUCTION
(ENGLISH,FRENCH,SPANISH)
3-861-618-21 MANUAL, INSTRUCTION
(GERMAN,DUTCH,ITALIAN,PORTUGUESE)(AEP)
3-861-618-31 MANUAL, INSTRUCTION
(SWEDISH,DANNISH,FINISH)(AEP)
3-861-618-41 MANUAL, INSTRUCTION
(ENGLISH,POLISH,RUSSIAN)(AEP)
3-861-618-51 MANUAL, INSTRUCTION (HUNGARIAN)(AEP)
3-861-618-61 MANUAL, INSTRUCTION (CZECH)(AEP)
3-861-618-81 MANUAL, INSTRUCTION (GREEK)(AEP)
4-962-615-01 COVER, BATTERY (FOR RM-D420)(XE320)
**************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-621-775-10 SCREW +B 2.6X4
#3 7-621-255-15 SCREW +P 2X3
#4 7-685-134-19 SCREW +BTP 2.6X8 TYPE2 N-S
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number
specified.
CDP-XE220/XE320
