Sony CDX-C4900R - Default Chapter; Sub Panel Assy; CD Mechanism Block

12
4 CN301
5 CD mechanism block
7 bracket (CD)
3
6 PTT 2.6x6
1 PTT 2.6x
6
2 PTT 2.6x6
1 PTT 2.6x8
2 PTT 2.6x8
4 two claws
3 claw
6 sub panel assy
5 CN500
2-2. CD MECHANISM BLOCK
SECTION 2
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
2-1. SUB PANEL ASSY
