13
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference
number, please include the board.
KEY
KEY BOARD
**********
1-694-660-11 CONDUCTIVE BOARD, CONNECTION
* 3-040-992-02 HOLDER (LCD)
* 3-040-993-01 PLATE (LCD), LIGHT GUIDE
* 3-040-997-02 PLATE (LCD), GROUND
3-041-371-11 SHEET (REFLECTOR)
< CAPACITOR >
C951 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C952 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C953 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C954 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C955 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C956 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
< CONNECTOR >
CN901 1-794-065-21 PLUG, CONNECTOR 14P
< DIODE >
D901 8-719-158-49 DIODE UDZ-TE-17-12B
D902 8-719-056-82 DIODE UDZ-TE-17-6.2B
D903 8-719-056-82 DIODE UDZ-TE-17-6.2B
D904 8-719-056-82 DIODE UDZ-TE-17-6.2B
D951 8-719-976-99 DIODE UDZ-TE-17-5.1B
D952 8-719-976-99 DIODE UDZ-TE-17-5.1B
< IC >
IC901 8-759-366-34 IC LC75824E
IC951 8-749-012-25 IC RS-170-TU
< LIQUID CRYSTAL DISPLAY >
LCD901 1-803-906-11 DISPLAY PANEL, LIQUID CRYSTAL
(C4900R/C5000R)
LCD901 1-803-906-31 DISPLAY PANEL, LIQUID CRYSTAL (C5000RX)
< DIODE >
LED901 8-719-061-16 LED CL-190SR-CD-T (C5000RX)
LED901 8-719-078-15 LED CL-165Y/PG-D-T (C4900R/C5000R)
LED902 8-719-061-16 LED CL-190SR-CD-T (C5000RX)
LED902 8-719-078-15 LED CL-165Y/PG-D-T (C4900R/C5000R)
LED903 8-719-061-16 LED CL-190SR-CD-T (C5000RX)
LED903 8-719-078-15 LED CL-165Y/PG-D-T (C4900R/C5000R)
LED904 8-719-061-16 LED CL-190SR-CD-T (C5000RX)
LED904 8-719-078-15 LED CL-165Y/PG-D-T (C4900R/C5000R)
LED910 8-719-078-19 LED LWA673-R1S2
LED911 8-719-078-19 LED LWA673-R1S2
LED912 8-719-078-19 LED LWA673-R1S2
LED913 8-719-078-19 LED LWA673-R1S2
< SWITCH >
LSW901 1-771-610-11 SWITCH, TACTILE (WITH LED) (OFF)
(C4900R/C5000R)
LSW901 1-771-883-11 SWITCH, TACTILE (WITH LED) (OFF)
(C5000RX)
LSW902 1-762-620-21 SWITCH, KEY BOARD (WITH LED) (SOURCE)
(C4900R/C5000R)
LSW902 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (SOURCE)
(C5000RX)
LSW903 1-762-620-21 SWITCH, KEY BOARD (WITH LED) (SOUND)
(C4900R/C5000R)
LSW903 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (SOUND)
(C5000RX)
LSW904 1-762-620-21 SWITCH, KEY BOARD (WITH LED) (MENU)
(C4900R/C5000R)
LSW904 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (MENU)
(C5000RX)
LSW905 1-762-620-21 SWITCH, KEY BOARD (WITH LED) (DSPL/PTY)
(C4900R/C5000R)
LSW905 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (DSPL/PTY)
(C5000RX)
LSW906 1-762-620-21 SWITCH, KEY BOARD (WITH LED) (LIST)
(C4900R/C5000R)
LSW906 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (LIST)
(C5000RX)
LSW907 1-762-620-21 SWITCH, KEY BOARD (WITH LED) (ENTER)
(C4900R/C5000R)
LSW907 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (ENTER)
(C5000RX)
LSW908 1-771-610-11 SWITCH, TACTILE (WITH LED) (MODE)
(C4900R/C5000R)
LSW908 1-771-883-11 SWITCH, TACTILE (WITH LED) (MODE)
(C5000RX)
LSW909 1-762-737-11 SWITCH, KEY BOARD (WITH LED) (D-BASS)
LSW910 1-762-620-21 SWITCH, KEY BOARD (WITH LED) (TA)
(C4900R/C5000R)
LSW910 1-771-476-11 SWITCH, KEY BOARD (WITH LED) (TA)
(C5000RX)
LSW911 1-762-620-21 SWITCH, KEY BOARD (WITH LED) (AF)
(C4900R/C5000R)
1-3. Electrical Parts List
