55
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SERVO SUB
The components identified by
mark 0 or dotted line with mark.
0 are critical for safety.
Replace only with part number
specified.
R564 1-216-845-11 METAL CHIP 100K 5% 1/16W
R568 1-216-837-11 METAL CHIP 22K 5% 1/16W
R569 1-216-809-11 METAL CHIP 100 5% 1/16W
R570 1-216-821-11 METAL CHIP 1K 5% 1/16W
R572 1-216-809-11 METAL CHIP 100 5% 1/16W
R590 1-216-845-11 METAL CHIP 100K 5% 1/16W
R594 1-216-845-11 METAL CHIP 100K 5% 1/16W
R595 1-216-845-11 METAL CHIP 100K 5% 1/16W
R599 1-216-821-11 METAL CHIP 1K 5% 1/16W
< VIBRATOR >
X1 1-781-758-21 VIBRATOR, CERAMIC (CHIP TYPE) (10MHz)
X2 1-781-759-21 VIBRATOR, CERAMIC (CHIP TYPE) (16MHz)
*************************************************************
* 1-659-834-11 SUB BOARD
**********
< CONNECTOR >
CN1 1-770-347-21 CONNECTOR, FPC 6P
*************************************************************
* 1-677-056-11 SUB (CD) BOARD
**************
< CONNECTOR >
CNP801 1-794-064-11 SOCKET, CONNECTOR 14P
CNP802 1-792-195-11 CABLE, FLEXIBLE FLAT
< DIODE >
D801 8-719-056-82 DIODE UDZ-TE-17-6.2B
D802 8-719-056-82 DIODE UDZ-TE-17-6.2B
D803 8-719-056-82 DIODE UDZ-TE-17-6.2B
D804 8-719-056-82 DIODE UDZ-TE-17-6.2B
D805 8-719-056-82 DIODE UDZ-TE-17-6.2B
D806 8-719-109-97 DIODE RD6.8ESB2
LED801 8-719-037-97 LED CL-190R-CD-T (INSERT MARK)
(C5000RX)
LED801 8-719-038-07 LED CL-190PG-CD-T (INSERT MARK)
(C4900R/C5000R)
LED802 8-719-037-97 LED CL-190R-CD-T (INSERT MARK)
(C5000RX)
LED802 8-719-038-07 LED CL-190PG-CD-T (INSERT MARK)
(C4900R/C5000R)
LED803 8-719-037-97 LED CL-190R-CD-T (INSERT MARK)
(C5000RX)
LED803 8-719-038-07 LED CL-190PG-CD-T (INSERT MARK)
(C4900R/C5000R)
< SWITCH >
LSW801 1-771-609-11 SWITCH, TACTILE (WITH LED) (Z)
(C4900R/C5000R)
LSW801 1-771-883-21 SWITCH, TACTILE (WITH LED) (Z)
(C5000RX)
*************************************************************
MISCELLANEOUS
***************
9 1-776-527-51 CORD (WITH CONNECTOR) (ISO) (POWER)
(C4900R)
9 1-776-527-61 CORD (WITH CONNECTOR) (ISO) (POWER)
(C5000R/C5000RX)
201 X-3378-598-1 CHASSIS (OP) ASSY (INCLUDING M901)
207 1-659-880-11 MOTOR FLEXIBLE BOARD
0 210 8-820-103-03 PICK-UP, OPTICAL KSS-720A/K1RP
212 1-676-707-21 PICK-UP FLEXIBLE BOARD
F901 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) 10A
M902 A-3291-674-A MOTOR ASSY, SLED (SLED)
M903 A-3315-039-A MOTOR SUB ASSY, LD (LOADING)
*************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
3-044-183-11 MANUAL, INSTRUCTION (ENGLISH,SPANISH,
SWEDISH,PORTUGUESE,RUSSIAN) (AEP,UK)
3-044-183-21 MANUAL, INSTRUCTION (FRENCH,GERMAN,
DUTCH,ITALIAN,GREEK) (AEP)
3-044-183-31 MANUAL, INSTRUCTION (GERMAN) (G)
3-044-188-11 MANUAL, INSTRUCTION INSTALL (ENGLISH,
SPANISH,SWEDISH,PORTUGUESE,RUSSIAN)
(AEP,UK)
3-044-188-21 MANUAL, INSTRUCTION INSTALL (FRENCH,
GERMAN,DUTCH,ITALIAN,GREEK) (AEP,G)
X-3378-490-1 CASE (PANEL) ASSY (for FRONT PANEL)
*************************************************************
**************
HARDWARE LIST
**************
#1 7-685-793-09 SCREW +PTT 2.6X8 (S)
#2 7-685-792-09 SCREW +PTT 2.6X6 (S)
#3 7-685-795-09 SCREW +PTT 2.6X12 (S)
#4 7-685-647-79 SCREW BVTP 3X10 TYPE 2 N-S
#5 7-621-772-20 SCREW +B 2X5
#6 7-685-791-09 SCREW +PTT 2.6X5 (S)
#7 7-628-253-00 SCREW +PS 2X4
#8 7-627-553-37 SCREW, PRECISION +P 2X3 TYPE 3
#9 7-627-553-17 SCREW, PRECISION +P 2X2 TYPE 3
#10 7-627-850-28 SCREW, PRECISION +P 1.4X3
#11 7-627-000-00 SCREW, PRECISION +P 1.7X2.2 TYPE 3
#12 7-685-106-19 SCREW +P 2X10 TYPE 2 NON-SLIT
*************************************************************
SUB (CD)
To Next Page
