Sony CDX-CA540X - Front Panel Section

31
CDX-CA540X/CA590X
4-2. FRONT PANEL SECTION
Ref. No. Part No. Description RemarkRef. No. Part No. Description Remark
#5
#5
not supplied
(DISPLAY board)
LCD901
not
supplied
not supplied
not supplied
not supplied
51
52
53
54
55
56
57
not supplied
not supplied
not supplied
51 A-3315-990-A PANEL COMPLETE ASSY, FRONT (CA590X)
51 A-3315-995-A PANEL COMPLETE ASSY, FRONT (CA540X)
52 X-3382-761-1 PANEL (S) ASSY, FRONT (CA590X)
52 X-3382-762-1 PANEL (S) ASSY, FRONT (CA540X)
53 3-246-534-01 SPRING (RELEASE)
54 X-3382-921-1 BUTTON ASSY (S)
55 X-3382-625-1 PANEL ASSY, FRONT BACK
56 X-3378-390-3 CASE ASSY (for FRONT PANEL)
57 1-694-989-11 CONDUCTIVE BOARD, CONNECTION
LCD901 1-805-077-11 DISPLAY PANEL, LIQUID CRYSTAL
#5 7-685-106-19 SCREW +P 2X10 TYPE2 NON-SLIT
