35
CDX-CA540X/CA590X
SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
DISPLAY
DISPLAY BOARD
**************
1-694-989-11 CONDUCTIVE BOARD, CONNECTION
< CAPACITOR >
C951 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C952 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C953 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN901 1-817-158-11 PLUG, CONNECTOR 14P
< DIODE >
D902 8-719-978-33 DIODE DTZ-TT11-6.8B
D903 8-719-978-33 DIODE DTZ-TT11-6.8B
D904 8-719-978-33 DIODE DTZ-TT11-6.8B
D905 8-719-988-61 DIODE 1SS355TE-17
D951 8-719-069-54 DIODE UDZS-TE-17-5.1B
< IC >
IC901 6-702-852-01 IC LC75824W-E
IC951 8-749-017-35 IC KSM-401N
< LIQUID CRYSTAL DISPLAY >
LCD901 1-805-077-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED901 8-719-053-09 LED SML-310VTT86 (SOURCE)
LED902 8-719-053-09 LED SML-310VTT86 (EQ3)
LED903 8-719-053-09 LED SML-310VTT86 (EQ3)
LED904 8-719-053-09 LED SML-310VTT86 (DSO)
LED905 8-719-053-09 LED SML-310VTT86 (DSO)
LED906 8-719-053-09 LED SML-310VTT86 (SEEK)
LED914 6-500-459-01 LED NSCW505T-ARS (LCD BACK LIGHT)
LED915 6-500-459-01 LED NSCW505T-ARS (LCD BACK LIGHT)
< SWITCH >
LSW901 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (OFF)
LSW902 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (MODE)
LSW903 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (SEL)
LSW904 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (VOL +)
LSW905 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (VOL –)
LSW906 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (ATT)
LSW907 1-771-883-11 SWITCH, TACTILE (WITH LED) (SENS)
LSW908 1-771-883-11 SWITCH, TACTILE (WITH LED) (1)
LSW909 1-771-883-11 SWITCH, TACTILE (WITH LED) (2)
LSW910 1-771-883-11 SWITCH, TACTILE (WITH LED) (3/REP)
LSW911 1-771-476-11 SWITCH, KEYBOARD (WITH LED)
(SEEK +/ M >)
LSW912 1-771-476-11 SWITCH, KEYBOARD (WITH LED)
(SEEK –/ m .)
LSW913 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (DSPL)
LSW914 1-771-883-11 SWITCH, TACTILE (WITH LED) (BTM)
LSW915 1-771-883-11 SWITCH, TACTILE (WITH LED) (6)
LSW916 1-771-883-11 SWITCH, TACTILE (WITH LED) (5)
LSW917 1-771-883-11 SWITCH, TACTILE (WITH LED) (4/SHUF)
< RESISTOR >
R901 1-216-819-11 METAL CHIP 680 5% 1/10W
R902 1-216-819-11 METAL CHIP 680 5% 1/10W
R903 1-216-819-11 METAL CHIP 680 5% 1/10W
R904 1-216-821-11 METAL CHIP 1K 5% 1/10W
R905 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R906 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R907 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R908 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R909 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R910 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R912 1-216-819-11 METAL CHIP 680 5% 1/10W
R913 1-216-819-11 METAL CHIP 680 5% 1/10W
R914 1-216-819-11 METAL CHIP 680 5% 1/10W
R915 1-216-821-11 METAL CHIP 1K 5% 1/10W
R916 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R917 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R918 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R919 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R920 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R940 1-216-815-11 METAL CHIP 330 5% 1/10W
R941 1-216-817-11 METAL CHIP 470 5% 1/10W
R942 1-216-815-11 METAL CHIP 330 5% 1/10W
R943 1-216-817-11 METAL CHIP 470 5% 1/10W
R951 1-216-815-11 METAL CHIP 330 5% 1/10W
R952 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R953 1-216-821-11 METAL CHIP 1K 5% 1/10W
R954 1-216-821-11 METAL CHIP 1K 5% 1/10W
R955 1-216-821-11 METAL CHIP 1K 5% 1/10W
R956 1-216-821-11 METAL CHIP 1K 5% 1/10W
R957 1-216-850-11 METAL CHIP 270K 5% 1/10W
