39
CDX-CA540X/CA590X
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
RELAY
R708 1-216-821-11 METAL CHIP 1K 5% 1/10W
R709 1-216-821-11 METAL CHIP 1K 5% 1/10W
R710 1-216-821-11 METAL CHIP 1K 5% 1/10W
R711 1-216-821-11 METAL CHIP 1K 5% 1/10W
R712 1-216-821-11 METAL CHIP 1K 5% 1/10W
R714 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R716 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R801 1-216-809-11 METAL CHIP 100 5% 1/10W
R802 1-216-809-11 METAL CHIP 100 5% 1/10W
R803 1-216-849-11 METAL CHIP 220K 5% 1/10W
R804 1-216-809-11 METAL CHIP 100 5% 1/10W
R805 1-216-809-11 METAL CHIP 100 5% 1/10W
R806 1-249-417-11 CARBON 1K 5% 1/4W
R807 1-216-849-11 METAL CHIP 220K 5% 1/10W
R809 1-216-849-11 METAL CHIP 220K 5% 1/10W
R810 1-249-417-11 CARBON 1K 5% 1/4W
R811 1-249-417-11 CARBON 1K 5% 1/4W
R812 1-249-417-11 CARBON 1K 5% 1/4W
R814 1-216-809-11 METAL CHIP 100 5% 1/10W
R815 1-216-809-11 METAL CHIP 100 5% 1/10W
R816 1-216-841-11 METAL CHIP 47K 5% 1/10W
R817 1-208-806-11 RES-CHIP 10K 0.5% 1/10W
R818 1-216-841-11 METAL CHIP 47K 5% 1/10W
R819 1-216-849-11 METAL CHIP 220K 5% 1/10W
R821 1-249-433-11 CARBON 22K 5% 1/4W
R822 1-216-849-11 METAL CHIP 220K 5% 1/10W
R823 1-249-417-11 CARBON 1K 5% 1/4W
R824 1-216-849-11 METAL CHIP 220K 5% 1/10W
R836 1-249-425-11 CARBON 4.7K 5% 1/4W
R840 1-216-809-11 METAL CHIP 100 5% 1/10W
R841 1-216-809-11 METAL CHIP 100 5% 1/10W
R842 1-216-821-11 METAL CHIP 1K 5% 1/10W
R844 1-247-807-31 CARBON 100 5% 1/4W
R845 1-247-807-31 CARBON 100 5% 1/4W
R846 1-247-807-31 CARBON 100 5% 1/4W
R847 1-216-809-11 METAL CHIP 100 5% 1/10W
R848 1-216-845-11 METAL CHIP 100K 5% 1/10W
R849 1-216-845-11 METAL CHIP 100K 5% 1/10W
R850 1-216-845-11 METAL CHIP 100K 5% 1/10W
R851 1-249-431-11 CARBON 15K 5% 1/4W
R852 1-216-809-11 METAL CHIP 100 5% 1/10W
R853 1-216-809-11 METAL CHIP 100 5% 1/10W
R855 1-216-821-11 METAL CHIP 1K 5% 1/10W
R856 1-249-409-11 CARBON 220 5% 1/4W
R857 1-249-409-11 CARBON 220 5% 1/4W
R858 1-216-841-11 METAL CHIP 47K 5% 1/10W
R859 1-216-809-11 METAL CHIP 100 5% 1/10W
R860 1-216-813-11 METAL CHIP 220 5% 1/10W
R901 1-249-425-11 CARBON 4.7K 5% 1/4W
R906 1-249-425-11 CARBON 4.7K 5% 1/4W
R907 1-216-841-11 METAL CHIP 47K 5% 1/10W
R908 1-216-841-11 METAL CHIP 47K 5% 1/10W
R909 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R913 1-249-417-11 CARBON 1K 5% 1/4W
R914 1-216-821-11 METAL CHIP 1K 5% 1/10W
R916 1-249-413-11 CARBON 470 5% 1/4W
R917 1-249-409-11 CARBON 220 5% 1/4W
R918 1-216-845-11 METAL CHIP 100K 5% 1/10W
R919 1-249-421-11 CARBON 2.2K 5% 1/4W
R920 1-216-849-11 METAL CHIP 220K 5% 1/10W
R922 1-208-806-11 RES-CHIP 10K 0.5% 1/10W
R923 1-208-806-11 RES-CHIP 10K 0.5% 1/10W
R924 1-249-404-00 CARBON 82 5% 1/4W
R925 1-249-404-00 CARBON 82 5% 1/4W
R926 1-249-404-00 CARBON 82 5% 1/4W
R927 1-249-404-00 CARBON 82 5% 1/4W
R928 1-249-404-00 CARBON 82 5% 1/4W
R929 1-249-404-00 CARBON 82 5% 1/4W
R930 1-216-845-11 METAL CHIP 100K 5% 1/10W
R931 1-249-421-11 CARBON 2.2K 5% 1/4W
R932 1-249-421-11 CARBON 2.2K 5% 1/4W
R933 1-216-821-11 METAL CHIP 1K 5% 1/10W
R934 1-216-041-00 METAL CHIP 470 5% 1/10W
R935 1-249-395-11 CARBON 15 5% 1/4W
R936 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R937 1-216-041-00 METAL CHIP 470 5% 1/10W
R951 1-216-821-11 METAL CHIP 1K 5% 1/10W
R952 1-216-809-11 METAL CHIP 100 5% 1/10W
R953 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
SW801 1-786-458-11 SWITCH, PUSH (1 KEY) (NOSE DET)
SW802 1-762-638-21 SWITCH, TACTILE (RESET)
SW803 1-571-478-11 SWITCH, SLIDE (FREQUENCY SELECT)
< THERMISTOR (POSITIVE) >
TH851 1-801-792-21 THERMISTOR, POSITIVE
TH901 1-809-148-11 THERMISTOR PTH8L07AR2R0M1B510
< TUNER >
TU601 A-3220-835-A TUNER UNIT (TUX-010)
< VIBRATOR >
X601 1-781-246-21 VIBRATOR, CRYSTAL (10.25MHz)
X801 1-795-259-11 VIBRATOR, CERAMIC (8.38MHz)
X802 1-567-098-41 VIBRATOR, CRYSTAL (32kHz)
*************************************************************
RELAY BOARD
************
1-792-173-11 CABLE, FLAT (FFC) 12P (CNP903)
< CONNECTOR >
CNP902 1-817-159-11 SOCKET, CONNECTOR 14P
< DIODE >
LED930 8-719-082-38 LED CL-270SR-C-TS (DOOR INDICATOR)
LED931 8-719-053-09 LED SML-310VTT86 (Z)
< RESISTOR >
R930 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R931 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R932 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
