Sony CDX-CA710X - Electrical Parts List (Resistors, Capacitors); Resistors, Capacitors, and Switches

38
CDX-CA710X/CA790X
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
LIMITKEY
R922 1-216-027-00 METAL CHIP 120 5% 1/10W
R926 1-216-809-11 METAL CHIP 100 5% 1/10W
R927 1-216-809-11 METAL CHIP 100 5% 1/10W
R928 1-216-809-11 METAL CHIP 100 5% 1/10W
R931 1-216-025-11 RES-CHIP 100 5% 1/10W
R932 1-216-025-11 RES-CHIP 100 5% 1/10W
R936 1-216-821-11 METAL CHIP 1K 5% 1/10W
R937 1-216-821-11 METAL CHIP 1K 5% 1/10W
R938 1-216-821-11 METAL CHIP 1K 5% 1/10W
R940 1-216-025-11 RES-CHIP 100 5% 1/10W
R941 1-216-027-00 METAL CHIP 120 5% 1/10W
R942 1-216-027-00 METAL CHIP 120 5% 1/10W
R946 1-216-025-11 RES-CHIP 100 5% 1/10W
R947 1-216-027-00 METAL CHIP 120 5% 1/10W
R948 1-216-027-00 METAL CHIP 120 5% 1/10W
R950 1-216-027-00 METAL CHIP 120 5% 1/10W
R951 1-216-025-11 RES-CHIP 100 5% 1/10W
R958 1-216-809-11 METAL CHIP 100 5% 1/10W
R959 1-216-809-11 METAL CHIP 100 5% 1/10W
R970 1-216-017-11 RES-CHIP 47 5% 1/10W
R971 1-216-017-11 RES-CHIP 47 5% 1/10W
R976 1-216-023-00 METAL CHIP 82 5% 1/10W
R982 1-216-023-00 METAL CHIP 82 5% 1/10W
R983 1-216-023-00 METAL CHIP 82 5% 1/10W
R984 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R985 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R986 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R987 1-216-023-00 METAL CHIP 82 5% 1/10W
R990 1-216-857-11 METAL CHIP 1M 5% 1/10W
R991 1-216-840-11 METAL CHIP 39K 5% 1/10W
R992 1-216-821-11 METAL CHIP 1K 5% 1/10W
R993 1-216-821-11 METAL CHIP 1K 5% 1/10W
R994 1-216-821-11 METAL CHIP 1K 5% 1/10W
R995 1-216-817-11 METAL CHIP 470 5% 1/10W
R996 1-216-817-11 METAL CHIP 470 5% 1/10W
R997 1-216-821-11 METAL CHIP 1K 5% 1/10W
R998 1-216-809-11 METAL CHIP 100 5% 1/10W
R999 1-216-864-11 METAL CHIP 0 5% 1/10W
< ROTARY ENCODER >
RE901 1-477-144-12 ENCODER, ROTARY (VOLUME CONTROL)
< SWITCH >
S903 1-771-884-11 SWITCH, TACTILE (WITH LED) (DSO)
S912 1-771-884-11 SWITCH, TACTILE (WITH LED) (ENTER)
S914 1-771-884-11 SWITCH, TACTILE (WITH LED) (EQ7)
S917 1-771-884-11 SWITCH, TACTILE (WITH LED) (LIST)
*************************************************************
1-659-835-21 LIMIT BOARD
***********
< SWITCH >
SW3 1-529-565-41 SWITCH, PUSH (1 KEY) (LIMIT)
*************************************************************
A-3274-595-A MAIN BOARD, COMPLETE (CA710X)
A-3274-596-A MAIN BOARD, COMPLETE (CA790X)
*********************
7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-795-09 SCREW +PTT 2.6X12 (S)
< CAPACITOR >
C101 1-128-528-11 ELECT 470uF 20% 16V
C102 1-104-942-11 ELECT 1uF 20% 50V
C103 1-135-473-21 ELECT 3300uF 20% 16V
C104 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C105 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C106 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C107 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C201 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C202 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C203 1-124-257-00 ELECT 2.2uF 20% 50V
C204 1-124-234-00 ELECT 47uF 20% 16V
C205 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C206 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C207 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C212 1-126-157-11 ELECT 10uF 20% 16V
C214 1-126-157-11 ELECT 10uF 20% 16V
C215 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C218 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C219 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C221 1-126-157-11 ELECT 10uF 20% 16V
C223 1-126-157-11 ELECT 10uF 20% 16V
C226 1-126-157-11 ELECT 10uF 20% 16V
C227 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C301 1-128-057-11 ELECT 330uF 20% 6.3V
C302 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C303 1-126-898-61 ELECT 220uF 20% 10V
C304 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C305 1-126-153-11 ELECT 22uF 20% 6.3V
C306 1-126-153-11 ELECT 22uF 20% 6.3V
C307 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C308 1-104-942-11 ELECT 1uF 20% 50V
C309 1-104-942-11 ELECT 1uF 20% 50V
C310 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C311 1-125-710-11 DOUBLE LAYERS 0.1F 5.5V
C312 1-124-584-00 ELECT 100uF 20% 10V
C313 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C314 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C315 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C316 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C317 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C318 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C322 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C325 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C326 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C327 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C331 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C332 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C333 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C334 1-216-864-11 METAL CHIP 0 5% 1/10W
C401 1-124-589-11 ELECT 47uF 20% 16V
