Sony CDX-CA710X - Chassis and Board Removal; Heat Sink and MJ Board Removal; Chassis (T.U) Assembly Disassembly

9
CDX-CA710X/CA790X
2-5. CHASSIS (T.U) ASSY
2-4. HEAT SINK, MJ BOARD
1 PTT 2.6x8
3 PTT 2.6x
8
4 heat sink
8 MJ board
7
6
5
2
PTT 2.6x10
4 chassis (T.U) assy
3 P 2x3
2 P 2x3
1 Unsolder the
lead wires.
black
red
white
