33
CDX-M50IP/MR50IP
IC800 NJM2387ADL3(TE2) (MAIN BOARD (3/4))
1 2 3 4 5
CURRENT
LIMIT
THERMAL
PROTECTION
OVERVOLTAGE
PROTECTION
BANDGAP
REFERENCE
VIN CONT VOUT VADJ GND
