Sony CF-CD73 - Printed Wiring Board - TUNER Section (ICF-CD73)

ICF-CD73/CD73V
2424
6-8. PRINTED WIRING BOARD – TUNER Section (ICF-CD73) – • See page 21 for Circuit Boards Location. :Uses unleaded solder.
C77
C78
(UK, IT)
(CND, MX)
(UK, IT)
JC24
IC2
IC1
TUNER BOARD
1-688-455-
11
(11)
L4
L3
AM FERRITE-ROD
ANTENNA
L2
T2
T1
L1
(SHIELD CASE)
TP
(VT)
TP
(GND)
TP
(ANT)
ANT1
FM LEAD WIRE
ANTENNA
1 2 3 4 5 6 7 8 9 10
A
B
C
D
E
1
11
LCD
BOARD
B
C13
(CND, MX)
(Page 28)
D1 C-7
D2 C-6
D3 C-6
D10 B-9
D11 B-9
IC1 D-7
IC2 D-3
• Semiconductor
Location
Ref. No. Location
Ver. 1.1
