ICF-CD73/CD73V
CD
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3683-347-A CD BOARD, COMPLETE
*******************
< CAPACITOR >
C701 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C702 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C703 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C705 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C706 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C708 1-126-160-11 ELECT 1uF 20% 50V
C709 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C710 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C711 1-115-156-11 CERAMIC CHIP 1uF 10V
C712 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C713 1-124-584-00 ELECT 100uF 20% 4V
C714 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C715 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C716 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C717 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C718 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C719 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C721 1-126-518-11 ELECT 470uF 20% 4V
C724 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C725 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C728 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C729 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C732 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C733 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C734 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C735 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C736 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C737 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C738 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C739 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C740 1-124-584-00 ELECT 100uF 20% 4V
C741 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C742 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C743 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C744 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C745 1-124-584-00 ELECT 100uF 20% 4V
C746 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C747 1-124-589-11 ELECT 47uF 20% 16V
C749 1-124-584-00 ELECT 100uF 20% 4V
C750 1-164-156-11 CERAMIC CHIP 0.1uF 25V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
C753 1-124-584-00 ELECT 100uF 20% 4V
C754 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C755 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C756 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C757 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C758 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C759 1-126-935-11 ELECT 470uF 20% 16V
C760 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C761 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C762 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C763 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C764 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C766 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C767 1-124-261-00 ELECT 10uF 20% 10V
C768 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C773 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C774 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C779 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C780 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C781 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CNP701 1-784-742-11 CONNECTOR, FFC 20P
CNP702 1-784-774-11 CONNECTOR, FFC 13P
< DIODE >
D701 8-719-052-88 DIODE 1N4002
< FERRITE BEAD >
FB701 1-469-701-21 FERRITE, EMI (SMD) (1608)
< IC >
IC701 6-701-796-01 IC LC78646E-US-E
IC702 6-704-047-01 IC BH6575FV-E2
< SHORT >
JC701 1-216-864-11 SHORT CHIP 0
JC702 1-216-864-11 SHORT CHIP 0
JC703 1-216-864-11 SHORT CHIP 0
< SHORT/COIL >
L701 1-216-864-11 SHORT CHIP 0
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
•Abbreviation
CND : Canadian model
IT : Italian model
Ver. 1.1
MX : Mexican model
To Next Page
