Sony CF-CD73 - Page 45

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
45
ICF-CD73/CD73V
CD JACK KEY
L702 1-414-398-11 INDUCTOR 10uH
L750 1-410-525-11 INDUCTOR 220uH
< TRANSISTOR >
Q701 8-729-054-57 TRANSISTOR KTN2907AS-RTK
Q702 8-729-905-35 TRANSISTOR 2SC4081-R
Q703 8-729-029-00 TRANSISTOR DTC115EUA-T106
Q704 8-729-028-91 TRANSISTOR DTA144EUA-T106
Q705 8-729-922-47 TRANSISTOR 2SB1184-TLR
< RESISTOR >
R701 1-216-833-11 METAL CHIP 10K 5% 1/10W
R702 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R703 1-216-837-11 METAL CHIP 22K 5% 1/10W
R704 1-216-817-11 METAL CHIP 470 5% 1/10W
R705 1-216-821-11 METAL CHIP 1K 5% 1/10W
R706 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R707 1-216-833-11 METAL CHIP 10K 5% 1/10W
R709 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R710 1-216-833-11 METAL CHIP 10K 5% 1/10W
R712 1-216-849-11 METAL CHIP 220K 5% 1/10W
R713 1-216-853-11 METAL CHIP 470K 5% 1/10W
R714 1-216-849-11 METAL CHIP 220K 5% 1/10W
R715 1-216-853-11 METAL CHIP 470K 5% 1/10W
R716 1-216-809-11 METAL CHIP 100 5% 1/10W
R717 1-216-805-11 METAL CHIP 47 5% 1/10W
R718 1-216-805-11 METAL CHIP 47 5% 1/10W
R719 1-216-809-11 METAL CHIP 100 5% 1/10W
R720 1-216-809-11 METAL CHIP 100 5% 1/10W
R721 1-216-864-11 SHORT CHIP 0
R722 1-216-864-11 SHORT CHIP 0
R723 1-216-817-11 METAL CHIP 470 5% 1/10W
R724 1-216-837-11 METAL CHIP 22K 5% 1/10W
R725 1-216-821-11 METAL CHIP 1K 5% 1/10W
R726 1-216-821-11 METAL CHIP 1K 5% 1/10W
R727 1-216-821-11 METAL CHIP 1K 5% 1/10W
R728 1-216-809-11 METAL CHIP 100 5% 1/10W
R729 1-216-809-11 METAL CHIP 100 5% 1/10W
R730 1-216-821-11 METAL CHIP 1K 5% 1/10W
R731 1-216-809-11 METAL CHIP 100 5% 1/10W
R732 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R733 1-216-841-11 METAL CHIP 47K 5% 1/10W
R734 1-216-813-11 METAL CHIP 220 5% 1/10W
R735 1-216-817-11 METAL CHIP 470 5% 1/10W
R736 1-216-813-11 METAL CHIP 220 5% 1/10W
R737 1-216-817-11 METAL CHIP 470 5% 1/10W
R738 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R739 1-216-833-11 METAL CHIP 10K 5% 1/10W
R740 1-216-813-11 METAL CHIP 220 5% 1/10W
R741 1-216-821-11 METAL CHIP 1K 5% 1/10W
R742 1-216-797-11 METAL CHIP 10 5% 1/10W
R743 1-216-864-11 SHORT CHIP 0
R744 1-216-809-11 METAL CHIP 100 5% 1/10W
R745 1-216-841-11 METAL CHIP 47K 5% 1/10W
R746 1-216-845-11 METAL CHIP 100K 5% 1/10W
R747 1-216-849-11 METAL CHIP 220K 5% 1/10W
R751 1-216-837-11 METAL CHIP 22K 5% 1/10W
R753 1-216-833-11 METAL CHIP 10K 5% 1/10W
R754 1-216-841-11 METAL CHIP 47K 5% 1/10W
R756 1-216-837-11 METAL CHIP 22K 5% 1/10W
R757 1-216-841-11 METAL CHIP 47K 5% 1/10W
R759 1-216-837-11 METAL CHIP 22K 5% 1/10W
R760 1-216-841-11 METAL CHIP 47K 5% 1/10W
R762 1-216-837-11 METAL CHIP 22K 5% 1/10W
R769 1-216-837-11 METAL CHIP 22K 5% 1/10W
R770 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R771 1-216-833-11 METAL CHIP 10K 5% 1/10W
R772 1-216-833-11 METAL CHIP 10K 5% 1/10W
R773 1-216-841-11 METAL CHIP 47K 5% 1/10W
< VIBRATOR >
X701 1-781-801-21 VIBRATOR, CERAMIC (16.9344MHz)
**************************************************************
* A-3683-364-A JACK BOARD, COMPLETE
(CD73: CND, MX/CD73V)
* A-3683-385-A JACK BOARD, COMPLETE (CD73: UK, IT)
*********************
< CAPACITOR >
C901 1-126-767-11 ELECT 1000uF 20% 16V
< CONNECTOR >
* CNP901 1-785-669-11 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
D901 8-719-052-88 DIODE 1N4002
D902 8-719-052-88 DIODE 1N4002 (CD73: UK, IT)
< JACK >
J901 1-580-681-21 JACK, DC (POLARITY UNIFIED TYPE)
(DC IN 6V)
< CABLE HOLDER >
* KH901 1-565-385-11 HOLDER, CABLE 4P
< COIL >
L901 1-456-379-11 COIL, CHOKE 47uH
< RESISTOR >
R901 1-216-821-11 METAL CHIP 1K 5% 1/10W
R902 1-247-807-31 CARBON 100 5% 1/4W
**************************************************************
* A-3683-352-A KEY BOARD, COMPLETE
********************
< CONNECTOR >
* CNP601 1-785-672-11 PIN, CONNECTOR (PC BOARD) 6P
* CNP602 1-785-669-21 PIN, CONNECTOR (PC BOARD) 3P
< RESISTOR >
R601 1-216-849-11 METAL CHIP 220K 5% 1/10W
R602 1-216-853-11 METAL CHIP 470K 5% 1/10W
R603 1-216-849-11 METAL CHIP 220K 5% 1/10W
Ver. 1.1
