Sony CF-CD73 - Cabinet (Upper) Section; Chassis (Main) Section

7
ICF-CD73/CD73V
3-3. CABINET (UPPER) SECTION
3-4. CHASSIS (MAIN) SECTION
3 two screws
(2.6
× 8)
4 two claws
5 cabinet (upper) section
2 connector
(CNP602)
1 connector
(CNP601
)
1 flat cable
(CNP702)
2 connector
(CNP303)
3 two screws
(2.6
× 8)
5 two screws
(2.6
× 8)
6 two screws
(2.6
× 8)
9 chassis (main) section
8 Remove the solder
of FM lead wire antenna
(ANT1).
7 cabinet (front) section
4 CD board
