Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
49
ICF-CD73/CD73V
C325 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C326 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C327 1-124-231-61 ELECT 4.7uF 20% 16V
C333 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C334 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C335 1-124-231-61 ELECT 4.7uF 20% 16V
< CONNECTOR >
CNP301 1-568-854-11 CONNECTOR, FFC 11P
* CNP302 1-785-670-11 PIN, CONNECTOR (PC BOARD) 4P
* CNP303 1-785-669-11 PIN, CONNECTOR (PC BOARD) 3P
* CNP304 1-785-656-21 PIN, CONNECTOR (PC BOARD) 4P
< DIODE >
D101 8-719-911-19 DIODE 1SS119-25
D201 8-719-911-19 DIODE 1SS119-25
D301 8-719-052-88 DIODE 1N4002
D302 8-719-109-63 DIODE RD3.0ESB2
D303 8-719-911-19 DIODE 1SS119-25
D304 8-719-911-19 DIODE 1SS119-25
D305 8-719-109-97 DIODE RD6.8ESB2
D307 8-719-109-97 DIODE RD6.8ESB2
D308 8-719-988-61 DIODE 1SS355TE-17
D309 8-719-911-19 DIODE 1SS119-25
D310 8-719-911-19 DIODE 1SS119-25
D311 8-719-911-19 DIODE 1SS119-25
D312 8-719-911-19 DIODE 1SS119-25
< IC >
IC301 6-704-036-01 IC XC62HR3302PR
IC303 8-759-366-92 IC LA4525-E
< COIL >
L301 1-412-006-31 INDUCTOR 10uH
L302 1-456-379-11 INDUCTOR 47uH
< TRANSISTOR >
Q101 8-729-922-87 TRANSISTOR 2SD1757K-RS
Q201 8-729-922-87 TRANSISTOR 2SD1757K-RS
Q301 8-729-026-52 TRANSISTOR 2SA1576A-T106-R
Q302 8-729-801-84 TRANSISTOR 2SB1013-4
Q303 8-729-907-00 TRANSISTOR DTC114EU
Q304 8-729-905-35 TRANSISTOR 2SC4081-R
Q305 8-729-905-35 TRANSISTOR 2SC4081-R
Q306 8-729-905-35 TRANSISTOR 2SC4081-R
Q307 8-729-021-82 TRANSISTOR 2SD2396K
< RESISTOR >
R102 1-216-849-11 METAL CHIP 220K 5% 1/10W
R103 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R104 1-216-833-11 METAL CHIP 10K 5% 1/10W
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-216-821-11 METAL CHIP 1K 5% 1/10W
R108 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R109 1-216-837-11 METAL CHIP 22K 5% 1/10W
R202 1-216-849-11 METAL CHIP 220K 5% 1/10W
R203 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R204 1-216-833-11 METAL CHIP 10K 5% 1/10W
R205 1-216-833-11 METAL CHIP 10K 5% 1/10W
R206 1-216-821-11 METAL CHIP 1K 5% 1/10W
R208 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R209 1-216-837-11 METAL CHIP 22K 5% 1/10W
R301 1-216-821-11 METAL CHIP 1K 5% 1/10W
R303 1-216-833-11 METAL CHIP 10K 5% 1/10W
R304 1-216-833-11 METAL CHIP 10K 5% 1/10W
R305 1-249-401-11 CARBON 47 5% 1/4W
R306 1-216-797-11 METAL CHIP 10 5% 1/10W
R307 1-216-841-11 METAL CHIP 47K 5% 1/10W
R308 1-216-821-11 METAL CHIP 1K 5% 1/10W
R309 1-216-797-11 METAL CHIP 10 5% 1/10W
R310 1-216-845-11 METAL CHIP 100K 5% 1/10W
R311 1-216-841-11 METAL CHIP 47K 5% 1/10W
R312 1-216-841-11 METAL CHIP 47K 5% 1/10W
R313 1-216-821-11 METAL CHIP 1K 5% 1/10W
R316 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R317 1-216-833-11 METAL CHIP 10K 5% 1/10W
R318 1-216-845-11 METAL CHIP 100K 5% 1/10W
R319 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R320 1-216-837-11 METAL CHIP 22K 5% 1/10W
R321 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R322 1-216-821-11 METAL CHIP 1K 5% 1/10W
R333 1-216-841-11 METAL CHIP 47K 5% 1/10W
R334 1-216-857-11 METAL CHIP 1M 5% 1/10W
< TRANSFORMER >
T301 1-449-138-11 TRANSFORMER, DC-DC CONVERTER
**************************************************************
* A-3683-360-A RELAY BOARD, COMPLETE
**********************
< CAPACITOR >
C777 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C778 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
CNP704 1-784-781-11 CONNECTOR, FFC 20P
CNP705 1-779-553-21 CONNECTOR, FFC (LIF (NON-ZIF)) 16P
* CNP706 1-566-761-11 PIN, CONNECTOR (PC BOARD) 6P
**************************************************************
* A-3683-356-A SW BOARD, COMPLETE
*******************
< SWITCH >
S551 1-571-936-11 SWITCH, LEAF (CD LID OPEN/CLOSE)
**************************************************************
POWER RELAY SW
Ver. 1.1
