Sony CFD-980 - ELECTRONIC BOARDS

— 13 —
Front cabinet sub assy
4 POWER SW board
7 H/P board
1 CN317
5 CN303
2 Screw
(+BVTP 2.6
× 10)
6 Screw
(2.6
× 10 +PWH)
3 POWER BRACKET board
3-5. CONTROL PANEL / SW BOARD
3-6. POWER SW BOARD / H/P BOARD
Upper cabinet assy
3 Screws 8pcs
5 SW1 board
4 CN310
1 Screws 4pcs
(+BVTP 3
× 12)
2 Panel subassy, control
