NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 57 —
SECTION 7
ELECTRICAL PARTS LIST
• Abbreviation
CND : Canadian
* 1-667-644-11 BATTERY BOARD
**************
3-017-954-01 SPRING (L) (–), BATTERY
3-939-057-01 SPRING (–), BACK UP
************************************************************
1-639-678-12 CD MOTOR BOARD
****************
< CONNECTOR >
CNP707 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
< SWITCH >
1-572-085-11 SWITCH, LEAF (CD DET)
************************************************************
* 1-667-642-11 DC BOARD
*********
< JACK >
J302 1-778-380-11 JACK,DC (POLARITY UNIFIED TYPE) (DC IN 9V)
************************************************************
* 1-667-647-11 H/P BOARD
*********
< CONNECTOR >
CN303 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
< JACK >
J301 1-566-891-11 JACK (2)
< RESISTOR >
R191 1-249-406-11 CARBON 120 5% 1/4W F
R291 1-249-406-11 CARBON 120 5% 1/4W F
************************************************************
* A-3293-761-A MAIN BOARD (US, CND)
***********
* A-3293-763-A MAIN BOARD (AEP)
***********
1-782-832-11 WIRE, PARALLEL (14 CORE)
7-685-646-79 SCREW, TAPPING +BV 3 × 8
< CAPACITOR >
C101 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C103 1-126-967-11 ELECT 47uF 20% 10V
C104 1-161-020-11 CERAMIC 0.039uF 10% 25V
C105 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C111 1-126-963-11 ELECT 4.7uF 20% 50V
C113 1-126-963-11 ELECT 4.7uF 20% 50V
C120 1-126-967-11 ELECT 47uF 20% 10V
C122 1-126-963-11 ELECT 4.7uF 20% 50V
C130 1-126-933-11 ELECT 100uF 20% 10V
C140 1-136-165-00 FILM 0.1uF 5% 50V
C150 1-126-963-11 ELECT 4.7uF 20% 50V
C160 1-162-290-31 CERAMIC 470PF 10% 50V
C170 1-162-282-31 CERAMIC 100PF 10% 50V
C180 1-162-286-21 CERAMIC 220PF 10% 50V
C190 1-162-282-31 CERAMIC 100PF 10% 50V
C191 1-126-926-11 ELECT 1000uF 20% 10V
C194 1-126-967-11 ELECT 47uF 20% 10V
C201 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C203 1-126-967-11 ELECT 47uF 20% 10V
C204 1-161-020-11 CERAMIC 0.039uF 10% 25V
C205 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C211 1-126-963-11 ELECT 4.7uF 20% 50V
C213 1-126-963-11 ELECT 4.7uF 20% 50V
C220 1-126-967-11 ELECT 47uF 20% 10V
C222 1-126-963-11 ELECT 4.7uF 20% 50V
C230 1-126-933-11 ELECT 100uF 20% 10V
C240 1-136-165-00 FILM 0.1uF 5% 50V
C250 1-126-963-11 ELECT 4.7uF 20% 50V
C260 1-162-290-31 CERAMIC 470PF 10% 50V
C270 1-162-282-31 CERAMIC 100PF 10% 50V
C280 1-162-286-21 CERAMIC 220PF 10% 50V
C290 1-162-282-31 CERAMIC 100PF 10% 50V
C291 1-126-926-11 ELECT 1000uF 20% 10V
C303 1-126-923-91 ELECT 220uF 20% 10V
C304 1-126-967-11 ELECT 47uF 20% 10V
