Sony CFD-980 - 5 Diagrams; Circuit Boards Location

— 22 —
SECTIO 5
DIAGRAMS
5-1. CIRCUIT BOARDS LOCATION
BATTERY board
REC board
SW2 board
SW1 board
H/P board
BRACKT POWER board
POWER SW board
MAIN board
DC board
LCD HOLDER board
RESET board
TUNER board
