Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 59 —
C824 1-162-851-91 CERAMIC 0.1uF 10% 16V
C825 1-162-294-21 CERAMIC 0.001uF 10% 50V
C826 1-162-294-21 CERAMIC 0.001uF 10% 50V
C827 1-162-294-21 CERAMIC 0.001uF 10% 50V
C828 1-162-282-21 CERAMIC 100pF 10% 50V
C829 1-162-282-21 CERAMIC 100pF 10% 50V
C830 1-162-282-21 CERAMIC 100pF 10% 50V
C834 1-162-282-21 CERAMIC 100pF 10% 50V
C835 1-162-294-21 CERAMIC 0.001uF 10% 50V
C836 1-162-300-21 CERAMIC 10000pF 30% 16V
C837 1-162-294-21 CERAMIC 0.001uF 10% 50V
C840 1-128-551-11 ELECT 22uF 20% 25V
C841 1-104-658-91 ELECT 100uF 20% 10V
C842 1-162-294-31 CERAMIC 0.001uF 10% 50V
C843 1-162-294-31 CERAMIC 0.001uF 10% 50V
C844 1-162-282-31 CERAMIC 100PF 10% 50V
C845 1-162-294-31 CERAMIC 0.001uF 10% 50V
C846 1-162-294-31 CERAMIC 0.001uF 10% 50V
C847 1-162-294-31 CERAMIC 0.001uF 10% 50V
C848 1-162-294-31 CERAMIC 0.001uF 10% 50V
C849 1-162-294-31 CERAMIC 0.001uF 10% 50V
C850 1-125-705-11 DOUBLE LAYER 0.22F 0 5.5V
C851 1-162-294-21 ELECT 0.001uF 10% 50V
C852 1-162-294-31 CERAMIC 0.001uF 10% 50V
C853 1-162-294-31 CERAMIC 0.001uF 10% 50V
C854 1-126-967-11 ELECT 47uF 20% 10V
C856 1-162-282-31 CERAMIC 100PF 10% 50V
C857 1-162-282-31 CERAMIC 100PF 10% 50V
< CONNECTOR >
* CN301 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
* CN302 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN303 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
* CN304 1-564-706-31 PIN, CONNECTOR (SMALL TYPE) 4P
* CN305 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
* CN307 1-695-336-11 PIN, CONNECTOR (PC BOARD) 13P
CN309 1-564-507-41 PLUG, CONNECTOR 4P (US, CND)
* CN309 1-564-507-11 PLUG, CONNECTOR 4P (AEP)
CN311 1-691-062-31 HOUSING, CONNECTOR 30P
* CN315 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
* CN318 1-564-518-11 PLUG, CONNECTOR 3P
CN701 1-770-168-11 CONNECTOR, FFC/FPC 16P
* CN702 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
< DIODE >
D301 8-719-109-97 DIODE RD6.8ES-B2
D302 8-719-109-89 DIODE RD5.6ESB2
D355 8-719-991-33 DIODE 1SS133T-77
D356 8-719-991-33 DIODE 1SS133T-77
D388 8-719-200-02 DIODE 10E2
D390 8-719-991-33 DIODE 1SS133T-77
D391 8-719-991-33 DIODE 1SS133T-77
D392 8-719-991-33 DIODE 1SS133T-77
< FUSE >
! F301 1-533-420-11 FUSE, GLASS CYLINDRICAL (DIA.5)
< FUSE HOLDER >
FH301 1-533-233-21 HOLDER, FUSE
FH302 1-533-233-21 HOLDER, FUSE
< IC >
IC301 8-759-264-71 IC TA2068N
IC302 8-759-432-41 IC BH3854AS
IC305 8-759-820-22 IC LA4597
IC701 8-752-074-34 IC CXA1782BQ
IC702 8-752-372-94 IC CXD2507AQ
IC703 8-759-478-60 IC BA6898S
IC704 8-759-426-44 IC 27C512-C35A65-V3.03
IC705 8-759-445-16 IC SM5859AF
IC706 8-759-427-15 IC MB814400C-70PFTN
IC801 8-752-894-00 IC CXP83120A-025Q
IC802 8-759-095-60 IC S-81250PG
IC802 8-759-479-70 IC S-81250SGY-Z
IC804 8-759-165-86 IC PST600I-T
< COIL >
L301 1-410-509-11 INDUCTOR 10uH
L701 7-611-031-61 WIRE, TINNING COPPER
L702 1-412-852-11 INDUCTOR 47uH
L703 1-414-142-31 INDUCTOR 10uH
L704 7-611-031-61 WIRE, TINNING COPPER
L705 1-414-142-31 INDUCTOR 1.0uH
L801 1-414-142-31 INDUCTOR 1.0uH
L802 1-414-142-31 INDUCTOR 1.0uH
L803 1-410-509-11 INDUCTOR 10uH
L806 1-414-142-31 INDUCTOR 1.0uH
L807 1-414-142-31 INDUCTOR 1.0uH
L808 1-414-142-31 INDUCTOR 1.0uH
L810 1-414-142-31 INDUCTOR 1.0uH
L811 1-414-142-31 INDUCTOR 1.0uH
< TRANSISTOR >
Q73 8-729-900-74 TRANSISTOR DTC143TS (US, CND)
Q301 8-729-801-84 TRANSISTOR 2SB1013-4
Q302 8-729-029-72 TRANSISTOR DTC114YS-TP
Q303 8-729-209-15 TRANSISTOR 2SD2012
Q304 8-729-209-15 TRANSISTOR 2SD2012
Q305 8-729-902-80 TRANSISTOR DTA114YS (US, CND)
Q306 8-729-029-72 TRANSISTOR DTC114YS-TP
Q309 8-729-281-53 TRANSISTOR 2SC1815-GR
Q310 8-729-119-78 TRANSISTOR 2SC403SP-51
Q311 8-729-119-78 TRANSISTOR 2SC403SP-51
Q701 8-729-037-02 TRANSISTOR KTA1266Y-AT
Q703 8-729-029-94 TRANSISTOR DTC143TSA
Q704 8-729-922-67 TRANSISTOR 2SC2410S-TPN
Q801 8-729-902-80 TRANSISTOR DTA114YS
Q802 8-729-029-72 TRANSISTOR DTC114YS-TP
Q803 8-729-922-66 TRANSISTOR 2SC2410SN
Q804 8-729-922-66 TRANSISTOR 2SC2410SN
Q805 8-729-902-80 TRANSISTOR DTA114YS
Q806 8-729-801-84 TRANSISTOR 2SB1013-4
Q807 8-729-902-80 TRANSISTOR DTA114YS
MAIN
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
