CFD-E77L
3-9. TAPE MECHANISM DECK
(MF-V5-117)
1 four screws
(BVTP3 × 10)
2 tape mechanism deck
(MF-V5-117)
3-8. CABINET FRONT ASSY
2 wire (flat type) (14 core
)
(CNP323)
7 two screws
(BVTP3 × 10)
6 screw
(BTP2.6 × 8)
4 Push the knob (stop/eject).
5
3 connector
(CNP321)
8 cabinet front assy
1 FFC cable 27P
(CNP801)
