Sony CFD-RS60CP Service Manual

57
CFD-RS60CP
IC401 6-710-637-01 IC BA5826SFP-E2
< TRANSISTOR >
Q301 6-551-120-01 TRANSISTOR 2SA2119K
< RESISTOR >
R101 1-216-813-11 METAL CHIP 220 5% 1/10W
R102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R104 1-216-295-11 SHORT CHIP 0
R105 1-216-857-11 METAL CHIP 1M 5% 1/10W
R106 1-216-821-11 METAL CHIP 1K 5% 1/10W
R108 1-500-445-21 FERRITE, EMI (SMD) (2012)
R109 1-216-809-11 METAL CHIP 100 5% 1/10W
R110 1-216-833-11 METAL CHIP 10K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-216-809-11 METAL CHIP 100 5% 1/10W
R114 1-216-833-11 METAL CHIP 10K 5% 1/10W
R118 1-216-845-11 METAL CHIP 100K 5% 1/10W
R119 1-216-864-11 SHORT CHIP 0
R121 1-216-809-11 METAL CHIP 100 5% 1/10W
R128 1-216-853-11 METAL CHIP 470K 5% 1/10W
R129 1-216-821-11 METAL CHIP 1K 5% 1/10W
R130 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R134 1-216-857-11 METAL CHIP 1M 5% 1/10W
R135 1-216-853-11 METAL CHIP 470K 5% 1/10W
R136 1-216-837-11 METAL CHIP 22K 5% 1/10W
R139 1-216-841-11 METAL CHIP 47K 5% 1/10W
R140 1-216-864-11 SHORT CHIP 0
R142 1-216-837-11 METAL CHIP 22K 5% 1/10W
R143 1-216-841-11 METAL CHIP 47K 5% 1/10W
R144 1-216-837-11 METAL CHIP 22K 5% 1/10W
R145 1-216-864-11 SHORT CHIP 0
R146 1-216-864-11 SHORT CHIP 0
R147 1-216-864-11 SHORT CHIP 0
R148 1-216-864-11 SHORT CHIP 0
R149 1-216-864-11 SHORT CHIP 0
R150 1-216-864-11 SHORT CHIP 0
R151 1-216-864-11 SHORT CHIP 0
R153 1-216-857-11 METAL CHIP 1M 5% 1/10W
R154 1-216-857-11 METAL CHIP 1M 5% 1/10W
R155 1-216-805-11 METAL CHIP 47 5% 1/10W
R156 1-216-809-11 METAL CHIP 100 5% 1/10W
R157 1-216-809-11 METAL CHIP 100 5% 1/10W
R201 1-216-295-11 SHORT CHIP 0
R202 1-216-295-11 SHORT CHIP 0
R203 1-216-809-11 METAL CHIP 100 5% 1/10W
R204 1-216-809-11 METAL CHIP 100 5% 1/10W
R205 1-216-809-11 METAL CHIP 100 5% 1/10W
R206 1-216-809-11 METAL CHIP 100 5% 1/10W
R207 1-216-809-11 METAL CHIP 100 5% 1/10W
R208 1-216-809-11 METAL CHIP 100 5% 1/10W
R209 1-216-809-11 METAL CHIP 100 5% 1/10W
R210 1-216-809-11 METAL CHIP 100 5% 1/10W
R211 1-216-809-11 METAL CHIP 100 5% 1/10W
R212 1-216-809-11 METAL CHIP 100 5% 1/10W
R213 1-216-809-11 METAL CHIP 100 5% 1/10W
R214 1-216-809-11 METAL CHIP 100 5% 1/10W
R216 1-216-809-11 METAL CHIP 100 5% 1/10W
R218 1-216-845-11 METAL CHIP 100K 5% 1/10W
R219 1-216-845-11 METAL CHIP 100K 5% 1/10W
R220 1-216-845-11 METAL CHIP 100K 5% 1/10W
R221 1-216-845-11 METAL CHIP 100K 5% 1/10W
R222 1-216-845-11 METAL CHIP 100K 5% 1/10W
R223 1-216-845-11 METAL CHIP 100K 5% 1/10W
R224 1-216-809-11 METAL CHIP 100 5% 1/10W
R301 1-216-845-11 METAL CHIP 100K 5% 1/10W
R302 1-216-864-11 SHORT CHIP 0
R303 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R304 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R402 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R405 1-216-833-11 METAL CHIP 10K 5% 1/10W
R408 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R414 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R415 1-216-841-11 METAL CHIP 47K 5% 1/10W
< VIBRATOR >
X102 1-795-101-21 VIBRATOR, CERAMIC (16.934MHz)
*************************************************************
A-1317-473-A CD KEY BOARD, COMPLETE
***********************
1-834-579-21 CABLE, FLEXIBLE FLAT (5 CORE) (CN401)
< CAPACITOR >
C401 1-135-834-11 CERAMIC CHIP 2.2uF 6.3V
< IC >
IC401 6-600-108-01 IC RPM7140 (IR)
< RESISTOR >
R401 1-216-813-11 METAL CHIP 220 5% 1/10W
R402 1-216-817-11 METAL CHIP 470 5% 1/10W
R403 1-216-821-11 METAL CHIP 1K 5% 1/10W
R404 1-216-821-11 METAL CHIP 1K 5% 1/10W
R405 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R406 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R407 1-216-821-11 METAL CHIP 1K 5% 1/10W
R408 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R409 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R410 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R411 1-216-833-11 METAL CHIP 10K 5% 1/10W
R412 1-216-813-11 METAL CHIP 220 5% 1/10W
R413 1-216-817-11 METAL CHIP 470 5% 1/10W
R414 1-216-821-11 METAL CHIP 1K 5% 1/10W
R415 1-216-821-11 METAL CHIP 1K 5% 1/10W
R416 1-216-841-11 METAL CHIP 47K 5% 1/10W
R417 1-216-845-11 METAL CHIP 100K 5% 1/10W
R505 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S401 1-786-726-11 SWITCH, TACTILE (CD-USB SYNC/REC1)
S402 1-786-726-11 SWITCH, TACTILE (SOUND)
S403 1-786-726-11 SWITCH, TACTILE (TUNE –/m)
S404 1-786-726-11 SWITCH, TACTILE (TUNE +/M)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BD91 CD KEY
