58
CFD-RS60CP
S405 1-786-726-11 SWITCH, TACTILE (PRESET –/.)
S406 1-786-726-11 SWITCH, TACTILE (PRESET +/>)
S407 1-786-726-11 SWITCH, TACTILE (u)
S408 1-786-726-11 SWITCH, TACTILE (x)
S409 1-786-726-11 SWITCH, TACTILE (ERASE)
S410 1-786-726-11 SWITCH, TACTILE (VOLUME +)
S411 1-786-726-11 SWITCH, TACTILE (VOLUME –)
S412 1-786-726-11 SWITCH, TACTILE (MEGABASS)
*************************************************************
A-1317-460-A HEADPHONE BOARD, COMPLETE
***************************
< CONNECTOR >
* CN371 1-815-552-21 PIN, CONNECTOR (PWB) 4P
CN372 1-815-552-11 PIN, CONNECTOR (PWB) 4P
< JACK >
J371 1-815-325-11 JACK (i )
< COIL >
L171 1-410-509-11 INDUCTOR 10uH
L271 1-410-509-11 INDUCTOR 10uH
< RESISTOR >
R171 1-216-809-11 METAL CHIP 100 5% 1/10W
R271 1-216-809-11 METAL CHIP 100 5% 1/10W
*************************************************************
A-1317-478-A LCD BOARD, COMPLETE
********************
1-831-999-21 CABLE, FLEXIBLE FLAT (15 CORE) (CN407)
2-547-143-01 PLATE, LIGHT GUIDE
2-547-164-01 HOLDER (LCD)
2-584-370-01 SHEET, LCD
< CAPACITOR >
C407 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C408 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN402 1-770-514-31 CONNECTOR, FFC/FPC 5P
< DIODE >
D401 6-501-437-01 DIODE SLI-343YC3F (LCD BACK LIGHT)
D403 8-719-059-97 LED L-34HD (OPR/BATT)
< IC >
IC402 6-709-360-01 IC NJU6533FA2
< COIL >
L401 1-410-509-11 INDUCTOR 10uH
< LIQUID CRYSTAL DISPLAY >
LCD401 1-802-533-11 DISPLAY PANEL, LIQUID CRYSTAL
< RESISTOR >
R425 1-216-833-11 METAL CHIP 10K 5% 1/10W
R426 1-216-833-11 METAL CHIP 10K 5% 1/10W
R427 1-216-833-11 METAL CHIP 10K 5% 1/10W
R428 1-216-833-11 METAL CHIP 10K 5% 1/10W
R429 1-216-833-11 METAL CHIP 10K 5% 1/10W
R430 1-216-833-11 METAL CHIP 10K 5% 1/10W
R431 1-216-833-11 METAL CHIP 10K 5% 1/10W
R432 1-216-833-11 METAL CHIP 10K 5% 1/10W
R433 1-216-833-11 METAL CHIP 10K 5% 1/10W
R434 1-216-833-11 METAL CHIP 10K 5% 1/10W
R435 1-216-833-11 METAL CHIP 10K 5% 1/10W
R436 1-216-833-11 METAL CHIP 10K 5% 1/10W
R437 1-216-833-11 METAL CHIP 10K 5% 1/10W
R438 1-216-833-11 METAL CHIP 10K 5% 1/10W
R439 1-216-833-11 METAL CHIP 10K 5% 1/10W
R440 1-216-833-11 METAL CHIP 10K 5% 1/10W
R441 1-216-833-11 METAL CHIP 10K 5% 1/10W
R442 1-216-833-11 METAL CHIP 10K 5% 1/10W
R443 1-216-833-11 METAL CHIP 10K 5% 1/10W
R444 1-216-833-11 METAL CHIP 10K 5% 1/10W
R445 1-216-833-11 METAL CHIP 10K 5% 1/10W
R446 1-216-833-11 METAL CHIP 10K 5% 1/10W
R447 1-216-833-11 METAL CHIP 10K 5% 1/10W
R448 1-216-833-11 METAL CHIP 10K 5% 1/10W
R449 1-216-833-11 METAL CHIP 10K 5% 1/10W
R450 1-216-833-11 METAL CHIP 10K 5% 1/10W
R451 1-216-833-11 METAL CHIP 10K 5% 1/10W
R452 1-216-833-11 METAL CHIP 10K 5% 1/10W
R453 1-216-833-11 METAL CHIP 10K 5% 1/10W
R454 1-216-833-11 METAL CHIP 10K 5% 1/10W
R455 1-216-833-11 METAL CHIP 10K 5% 1/10W
R456 1-216-833-11 METAL CHIP 10K 5% 1/10W
R457 1-216-833-11 METAL CHIP 10K 5% 1/10W
R459 1-216-813-11 METAL CHIP 220 5% 1/10W
R461 1-216-813-11 METAL CHIP 220 5% 1/10W
R462 1-216-813-11 METAL CHIP 220 5% 1/10W
R463 1-216-813-11 METAL CHIP 220 5% 1/10W
R464 1-216-813-11 METAL CHIP 220 5% 1/10W
R465 1-216-853-11 METAL CHIP 470K 5% 1/10W
R466 1-216-849-11 METAL CHIP 220K 5% 1/10W
R467 1-216-841-11 METAL CHIP 47K 5% 1/10W
R468 1-216-813-11 METAL CHIP 220 5% 1/10W
R470 1-216-813-11 METAL CHIP 220 5% 1/10W
R471 1-216-813-11 METAL CHIP 220 5% 1/10W
R472 1-216-817-11 METAL CHIP 470 5% 1/10W
R473 1-216-821-11 METAL CHIP 1K 5% 1/10W
R474 1-216-821-11 METAL CHIP 1K 5% 1/10W
R475 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R501 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R502 1-216-809-11 METAL CHIP 100 5% 1/10W
R503 1-216-809-11 METAL CHIP 100 5% 1/10W
R504 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S419 1-786-726-11 SWITCH, TACTILE (DISP/ENT/MEMORY)
S420 1-786-726-11 SWITCH, TACTILE (MODE)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CD KEY HEADPHONE LCD
To Next Page
