Sony CFD-RS60CP Service Manual

65
CFD-RS60CP
< VIBRATOR >
X1 1-795-449-11 VIBRATOR, CRYSTAL (75kHz)
*************************************************************
A-1317-463-A USB BOARD, COMPLETE
********************
< CAPACITOR >
C901 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C902 1-124-779-00 ELECT CHIP 10uF 20% 16V
C903 1-124-779-00 ELECT CHIP 10uF 20% 16V
C904 1-124-779-00 ELECT CHIP 10uF 20% 16V
C905 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C906 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C907 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C908 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C909 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C910 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C912 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C913 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C914 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C915 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C916 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C917 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C918 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C919 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C920 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C921 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C922 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C930 1-216-864-11 SHORT CHIP 0
< CONNECTOR >
CN901 1-770-160-21 PIN, CONNECTOR (PC BOARD) 2P
CN903 1-779-993-11 PIN, CONNECTOR (PWB) 5P
CN904 1-784-859-51 CONNECTOR, FFC (LIF(NON-ZIF)) 7P
CN907 1-784-833-51 CONNECTOR, FFC (LIF(NON-ZIF)) 21P
< DIODE >
D903 8-719-978-33 DIODE DTZ-TT11-6.8B
D904 8-719-978-33 DIODE DTZ-TT11-6.8B
D905 6-501-579-01 DIODE MC2837
< JUMPER RESISTOR >
FB901 1-216-295-11 SHORT CHIP 0
FB902 1-216-295-11 SHORT CHIP 0
< IC >
IC901 6-807-284-01 IC TMP92CD28AFG-2CB4
IC915 6-710-887-01 IC R5523N001B-TR-F
IC921 6-704-832-01 IC IS61LV6416-10TLT
< JUMPER RESISTOR >
JR902 1-216-295-11 SHORT CHIP 0
< RESISTOR >
R901 1-216-833-11 METAL CHIP 10K 5% 1/10W
R902 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R903 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R904 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R905 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R906 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R907 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R913 1-216-845-11 METAL CHIP 100K 5% 1/10W
R915 1-216-833-11 METAL CHIP 10K 5% 1/10W
R916 1-216-864-11 SHORT CHIP 0
R917 1-216-864-11 SHORT CHIP 0
R919 1-216-809-11 METAL CHIP 100 5% 1/10W
R920 1-216-833-11 METAL CHIP 10K 5% 1/10W
R921 1-216-845-11 METAL CHIP 100K 5% 1/10W
R922 1-216-845-11 METAL CHIP 100K 5% 1/10W
R923 1-216-802-11 METAL CHIP 27 5% 1/10W
R924 1-216-802-11 METAL CHIP 27 5% 1/10W
R925 1-216-835-11 METAL CHIP 15K 5% 1/10W
R926 1-216-835-11 METAL CHIP 15K 5% 1/10W
R928 1-216-864-11 SHORT CHIP 0
R932 1-216-809-11 METAL CHIP 100 5% 1/10W
R933 1-216-864-11 SHORT CHIP 0
R934 1-216-833-11 METAL CHIP 10K 5% 1/10W
R937 1-216-809-11 METAL CHIP 100 5% 1/10W
R938 1-216-809-11 METAL CHIP 100 5% 1/10W
R941 1-216-845-11 METAL CHIP 100K 5% 1/10W
R942 1-216-845-11 METAL CHIP 100K 5% 1/10W
R943 1-216-845-11 METAL CHIP 100K 5% 1/10W
R944 1-216-845-11 METAL CHIP 100K 5% 1/10W
R945 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R947 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R950 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R970 1-216-809-11 METAL CHIP 100 5% 1/10W
R971 1-216-809-11 METAL CHIP 100 5% 1/10W
R972 1-216-809-11 METAL CHIP 100 5% 1/10W
R973 1-216-809-11 METAL CHIP 100 5% 1/10W
R974 1-216-809-11 METAL CHIP 100 5% 1/10W
R975 1-216-809-11 METAL CHIP 100 5% 1/10W
R976 1-216-809-11 METAL CHIP 100 5% 1/10W
R977 1-216-809-11 METAL CHIP 100 5% 1/10W
R978 1-216-809-11 METAL CHIP 100 5% 1/10W
R979 1-216-809-11 METAL CHIP 100 5% 1/10W
R981 1-216-809-11 METAL CHIP 100 5% 1/10W
R982 1-216-809-11 METAL CHIP 100 5% 1/10W
R983 1-216-809-11 METAL CHIP 100 5% 1/10W
R984 1-216-809-11 METAL CHIP 100 5% 1/10W
R985 1-216-809-11 METAL CHIP 100 5% 1/10W
R986 1-216-809-11 METAL CHIP 100 5% 1/10W
< NETWORK RESISTOR >
RB921 1-234-944-21 RES, NETWORK 47X4 (1005)
RB922 1-234-944-21 RES, NETWORK 47X4 (1005)
RB923 1-234-944-21 RES, NETWORK 47X4 (1005)
RB924 1-234-944-21 RES, NETWORK 47X4 (1005)
< VIBRATOR >
X901 1-813-931-21 VIBRATOR, CRYSTAL (9MHz)
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TUNER USB

Sony CFD-RS60CP Specifications

General

Radio type	Portable
Tuner type	Digital
AM band range	530 - 1611 kHz
FM band range	87.5 - 108 MHz
Backlight	Yes
Product color	Black
Dimensions (WxDxH)	420 x 159 x 260 mm

Weight and Dimensions

Weight	3700 g
