Sony CFD-RS60CP Service Manual

66
CFD-RS60CP
A-1317-475-A USB CONNECT BOARD, COMPLETE
****************************
< CAPACITOR >
C1003 1-135-834-11 CERAMIC CHIP 2.2uF 6.3V
< DIODE >
D1003 8-719-978-33 DIODE DTZ-TT11-6.8B
D1004 8-719-978-33 DIODE DTZ-TT11-6.8B
< FERRITE BEAD >
FB1003 1-414-233-22 INDUCTOR, FERRITE BEAD
FB1004 1-414-233-22 INDUCTOR, FERRITE BEAD
< COIL >
L1001 1-456-799-11 COIL, COMMON MODE CHOKE
< CONNECTOR >
J1001 1-794-548-21 CONNECTOR, USB (A) ( )
*************************************************************
A-1317-465-A VOL BOARD, COMPLETE
********************
< CAPACITOR >
C152 1-126-160-11 ELECT 1uF 20% 50V
C153 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C154 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C155 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C156 1-126-163-11 ELECT 4.7uF 20% 50V
C157 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C158 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C159 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C160 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C161 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C162 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C252 1-126-160-11 ELECT 1uF 20% 50V
C253 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C254 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C255 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C256 1-126-163-11 ELECT 4.7uF 20% 50V
C257 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C258 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C259 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C260 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C261 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C262 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C351 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C352 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C353 1-124-261-11 ELECT 10uF 20% 10V
C354 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C355 1-125-972-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN351 1-815-558-11 PIN, CONNECTOR (PWB) 10P
< IC >
IC351 6-710-289-01 IC R2S15904SP
< JUMPER RESISTOR >
JC351 1-216-864-11 SHORT CHIP 0
< COIL >
L351 1-410-509-11 INDUCTOR 10uH
< RESISTOR >
R151 1-216-821-11 METAL CHIP 1K 5% 1/10W
R153 1-216-853-11 METAL CHIP 470K 5% 1/10W
R154 1-216-841-11 METAL CHIP 47K 5% 1/10W
R155 1-216-833-11 METAL CHIP 10K 5% 1/10W
R251 1-216-821-11 METAL CHIP 1K 5% 1/10W
R253 1-216-853-11 METAL CHIP 470K 5% 1/10W
R254 1-216-841-11 METAL CHIP 47K 5% 1/10W
R255 1-216-833-11 METAL CHIP 10K 5% 1/10W
R351 1-216-809-11 METAL CHIP 100 5% 1/10W
R352 1-216-809-11 METAL CHIP 100 5% 1/10W
R353 1-216-809-11 METAL CHIP 100 5% 1/10W
R354 1-216-809-11 METAL CHIP 100 5% 1/10W
R355 1-216-833-11 METAL CHIP 10K 5% 1/10W
R356 1-216-833-11 METAL CHIP 10K 5% 1/10W
*************************************************************
MISCELLANEOUS
***************
104 1-832-404-21 CABLE, FLEXIBLE FLAT (16 CORE)
105 1-832-644-21 CABLE, FLEXIBLE FLAT (27 CORE)
111 1-452-899-11 MAGNET
0115 8-820-126-02 OPTICAL PICK-UP (KSM-213CDP/C2NP)
165 1-500-868-11 CORE, FERRITE
206 1-832-824-21 CABLE, FLEXIBLE FLAT (11 CORE)
211 1-832-611-21 CABLE, FLEXIBLE FLAT (21 CORE)
218 1-500-868-11 CORE, FERRITE
253 1-832-833-21 CABLE, FLEXIBLE FLAT (13 CORE)
ANT1 1-754-376-11 ANTENNA, TELESCOPIC (FM)
C309 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
0F951 1-532-465-33 FUSE (3.15A/250V)
HE301 1-500-813-11 HEAD, ERASE (ERASE)
HRP301 3-266-053-01 HEAD, RP (REC/PB)
0J951 1-526-838-11 INLET, AC 2P (- AC IN) (E41,SP)
0J951 1-540-009-11 INLET, AC (- AC IN) (MX)
S201 1-771-853-11 SWITCH, DETECTION (LIMIT)
S801 1-692-960-11 SWITCH, PUSH (1 KEY)
(Z PUSH OPEN/CLOSE)
SP301 1-825-690-11 SPEAKER (DIA. 10cm) (L-CH)
SP302 1-825-690-11 SPEAKER (DIA. 10cm) (R-CH)
0T951 1-445-291-11 TRANSFORMER, POWER (MX)
0T951 1-445-292-11 TRANSFORMER, POWER (E41,SP)
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
USB CONNECT VOL

Sony CFD-RS60CP Specifications

General

Radio type	Portable
Tuner type	Digital
AM band range	530 - 1611 kHz
FM band range	87.5 - 108 MHz
Backlight	Yes
Product color	Black
Dimensions (WxDxH)	420 x 159 x 260 mm

Weight and Dimensions

Weight	3700 g
