46
CFD-S700
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R850 1-216-821-11 METAL CHIP 1K 5% 1/10W
R851 1-216-813-11 METAL CHIP 220 5% 1/10W
R852 1-216-813-11 METAL CHIP 220 5% 1/10W
R853 1-216-813-11 METAL CHIP 220 5% 1/10W
R854 1-216-841-11 METAL CHIP 47K 5% 1/10W
R859 1-216-821-11 METAL CHIP 1K 5% 1/10W
R860 1-216-841-11 METAL CHIP 47K 5% 1/10W
R861 1-216-821-11 METAL CHIP 1K 5% 1/10W
R862 1-216-821-11 METAL CHIP 1K 5% 1/10W
R865 1-216-841-11 METAL CHIP 47K 5% 1/10W
R866 1-216-845-11 METAL CHIP 100K 5% 1/10W
R867 1-216-821-11 METAL CHIP 1K 5% 1/10W
R868 1-216-821-11 METAL CHIP 1K 5% 1/10W
R869 1-216-821-11 METAL CHIP 1K 5% 1/10W
R870 1-216-821-11 METAL CHIP 1K 5% 1/10W
R871 1-216-821-11 METAL CHIP 1K 5% 1/10W
R872 1-216-821-11 METAL CHIP 1K 5% 1/10W
R901 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R902 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R903 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R951 1-216-841-11 METAL CHIP 47K 5% 1/10W
R952 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R954 1-216-821-11 METAL CHIP 1K 5% 1/10W
R955 1-216-821-11 METAL CHIP 1K 5% 1/10W
R958 1-216-813-11 METAL CHIP 220 5% 1/10W
R959 1-216-809-11 METAL CHIP 100 5% 1/10W
R960 1-216-864-11 METAL CHIP 0 5% 1/10W
< TRANSFORMER >
T1 1-433-741-11 TRANSFORMER, IF
T2 1-419-465-11 COIL (DET)
< VIBRATOR >
X1 1-760-130-11 VIBRATOR, CRYSTAL (75kHz)
X801 1-795-267-11 VIBRATOR, CRYSTAL (32.768kHz)
X802 1-781-775-11 VIBRATOR, CERAMIC (4.19MHz)
**************************************************************
* A-3347-877-A POWER BOARD, COMPLETE
(including INLET Board)(E92,MX)
***********************
* A-3347-888-A POWER BOARD, COMPLETE
(including INLET Board)(E15)
***********************
* A-3347-894-A POWER BOARD, COMPLETE
(including INLET Board)(SP)
***********************
* A-3364-837-A POWER BOARD, COMPLETE
(including INLET Board)(CND)
***********************
< CABLE HOLDER >
* KH905 1-573-287-11 HOLDER, CABLE 2P
**************************************************************
* A-3347-916-A POWER AMP BOARD, COMPLETE
***************************
7-685-646-79 SCREW, TAPPING +BV 3X8
< CAPACITOR >
C129 1-104-665-11 ELECT 100uF 20.00% 10V
C130 1-126-964-11 ELECT 10uF 20.00% 50V
C151 1-126-947-11 ELECT 47uF 20.00% 10V
C152 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C153 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C154 1-126-947-11 ELECT 47uF 20.00% 10V
C155 1-126-947-11 ELECT 47uF 20.00% 10V
C156 1-104-665-11 ELECT 100uF 20.00% 10V
C157 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C158 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C229 1-104-665-11 ELECT 100uF 20.00% 10V
C230 1-126-964-11 ELECT 10uF 20.00% 50V
C251 1-126-947-11 ELECT 47uF 20.00% 10V
C252 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C253 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C254 1-126-947-11 ELECT 47uF 20.00% 10V
C255 1-126-947-11 ELECT 47uF 20.00% 10V
C256 1-104-665-11 ELECT 100uF 20.00% 10V
C257 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C258 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C323 1-126-964-11 ELECT 10uF 20.00% 50V
C331 1-126-947-11 ELECT 47uF 20.00% 10V
< CONNECTOR >
* CNP303 1-815-555-11 PIN, CONNECTOR (PWB) 7P
* CNP322 1-815-555-11 PIN, CONNECTOR (PWB) 7P
< DIODE >
D101 8-719-988-61 DIODE 1SS355TE-17
D201 8-719-988-61 DIODE 1SS355TE-17
D323 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC101 8-759-426-51 IC BA5417
IC201 8-759-426-51 IC BA5417
< TRANSISTOR >
Q124 8-729-029-10 TRANSISTOR DTC143TU-T106
Q224 8-729-029-10 TRANSISTOR DTC143TU-T106
< RESISTOR >
R140 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R141 1-216-821-11 METAL CHIP 1K 5% 1/10W
R142 1-216-813-11 METAL CHIP 220 5% 1/10W
R145 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R146 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R147 1-216-821-11 METAL CHIP 1K 5% 1/10W
R148 1-216-817-11 METAL CHIP 470 5% 1/10W
R149 1-216-809-11 METAL CHIP 100 5% 1/10W
R150 1-216-809-11 METAL CHIP 100 5% 1/10W
R240 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R241 1-216-821-11 METAL CHIP 1K 5% 1/10W
R242 1-216-813-11 METAL CHIP 220 5% 1/10W
R245 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R246 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R247 1-216-821-11 METAL CHIP 1K 5% 1/10W
R248 1-216-817-11 METAL CHIP 470 5% 1/10W
R249 1-216-809-11 METAL CHIP 100 5% 1/10W
R250 1-216-809-11 METAL CHIP 100 5% 1/10W
R323 1-216-857-11 METAL CHIP 1M 5% 1/10W
**************************************************************
POWER AMP
Ver 1.1 2003.03
