47
CFD-S700
Ref. No. Part No. Description Remark
* A-3062-297-A PRE BOARD, COMPLETE
********************
< CAPACITOR >
C101 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C102 1-126-947-11 ELECT 47uF 20.00% 10V
C103 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C104 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C105 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C106 1-126-960-11 ELECT 1uF 20.00% 50V
C107 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C201 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C202 1-126-947-11 ELECT 47uF 20.00% 10V
C203 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C204 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C205 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C206 1-126-960-11 ELECT 1uF 20.00% 50V
C207 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C301 1-104-665-11 ELECT 100uF 20.00% 10V
C302 1-104-665-11 ELECT 100uF 20.00% 10V
C303 1-104-665-11 ELECT 100uF 20.00% 10V
C304 1-126-947-11 ELECT 47uF 20.00% 10V
C305 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C306 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C307 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< CONNECTOR >
CN303 1-568-830-11 CONNECTOR, FFC 11P
< IC >
IC301 8-759-264-71 IC TA2068N
< CABLE HOLDER >
JC301 1-216-864-11 METAL CHIP 0 5% 1/10W
JC302 1-216-864-11 METAL CHIP 0 5% 1/10W
JC303 1-216-864-11 METAL CHIP 0 5% 1/10W
JC304 1-216-864-11 METAL CHIP 0 5% 1/10W
< TRANSISTOR >
Q301 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
< RESISTOR >
R101 1-216-835-11 METAL CHIP 15K 5% 1/10W
R102 1-216-807-11 METAL CHIP 68 5% 1/10W
R103 1-216-843-11 METAL CHIP 68K 5% 1/10W
R104 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R105 1-216-835-11 METAL CHIP 15K 5% 1/10W
R110 1-216-809-11 METAL CHIP 100 5% 1/10W
R111 1-216-839-11 METAL CHIP 33K 5% 1/10W
R201 1-216-835-11 METAL CHIP 15K 5% 1/10W
R202 1-216-807-11 METAL CHIP 68 5% 1/10W
R203 1-216-843-11 METAL CHIP 68K 5% 1/10W
R204 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R205 1-216-835-11 METAL CHIP 15K 5% 1/10W
R210 1-216-025-11 RES-CHIP 100 5% 1/10W
R211 1-216-839-11 METAL CHIP 33K 5% 1/10W
R301 1-216-857-11 METAL CHIP 1M 5% 1/10W
R302 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R303 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
PRE
R304 1-216-821-11 METAL CHIP 1K 5% 1/10W
R305 1-216-811-11 METAL CHIP 150 5% 1/10W
R306 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R307 1-216-797-11 METAL CHIP 10 5% 1/10W
R308 1-216-837-11 METAL CHIP 22K 5% 1/10W
R309 1-216-805-11 METAL CHIP 47 5% 1/10W
< SWITCH >
S301 1-762-565-11 SWITCH, SLIDE (REC/PB)
< TRANSFORMER >
T301 1-416-041-11 TRANSFORMER, BIAS OSCILLATION
**************************************************************
* 1-682-250-11 SELECTION BOARD (E15)
****************
S901 1-552-921-00 SWITCH,POWER
(VOLTAGE CHANGE)(VOLTAGE SELECTOR)(E15)
**************************************************************
MISCELLANEOUS
**************
* 11 1-757-559-11 CABLE, FLEXIBLE FLAT (8 CORE)
* 102 1-757-560-11 CABLE, FLEXIBLE FLAT (11 CORE)
117 1-452-899-11 MAGNET
124 1-757-689-11 CABLE, FLEXIBLE FLAT (16 CORE)
* 125 1-757-561-11 CABLE, FLEXIBLE FLAT (14 CORE)
0251 8-820-161-02 DEVICE, OPTICAL KSS-213R/RP
ANT1 1-501-883-21 ANTENNA, TELESCOPIC
HE301 1-543-876-11 HEAD (ERASE)
HRP301 1-500-691-11 HEAD,MAGNETIC(RECORD/PLAYBACK)
LCD801 1-804-243-11 DISPLAY PANEL, LIQUID CRYSTAL
M702 X-2162-712-1 MOTOR GEAR ASSY R (RP) (SLED)
M801 A-3320-446-A MOTOR ASSY (CAPSTAN/RELL)
S801 1-692-960-11 SWITCH, PUSH (1 KEY) (OPEN/CLOSE)
S802 1-762-679-11 SWITCH, LEAF (TAPE PLAY)
SP101 1-825-423-11 SPEAKER (10cm) (L-CH)
SP201 1-825-423-11 SPEAKER (10cm) (R-CH)
0T901 1-439-766-11 TRANSFORMER, POWER (CND,E92,MX)
0T901 1-439-764-11 TRANSFORMER, POWER (E15)
0T901 1-439-765-11 TRANSFORMER, POWER (SP)
**************************************************************
ACCESSORIES
************
0 1-557-287-11 CORD, POWER (E92,MX)
0 1-769-412-21 CORD, POWER (E15,SP)
0 1-783-878-11 CORD, POWER (CND)
3-249-672-11 MANUAL, INSTRUCTION (ENGLISH)
(CND,E92,MX)
3-249-672-21 MANUAL, INSTRUCTION (SPANISH)(E92,MX)
3-249-672-31 MANUAL, INSTRUCTION (FRENCH)(CND)
3-249-672-41 MANUAL, INSTRUCTION (ENGLISH,SPANISH)
(E15,SP)
3-249-672-51 MANUAL, INSTRUCTION (FRENCH)(E15)
3-027-153-01 LID, BATTERY CASE (FOR RMT-CS700A)
A-3172-084-A REMOTE COMMANDER, RMT-CS700A//C (SET)
Ref. No. Part No. Description Remark
Ver 1.2 2003.11
SELECTION
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
