Sony CFD-V27 - Page 13

— 13 —
15
7
4
1
30
16
IC1
CV1
CF1
L1
FM Tracking
Adjustment
L2
FM Frequency
Coverage
Adjustment
T2
AM IF
Adjustment
L4
AM Frequency
Coverage
Adjustment
RV1
FM VCO
Adjustment
L3
AM Tracking
Adjustment
FM ANT IN
T1
FM IF
Adjustment
AM OSC
AM OSC
FM OSC
FM OSC
CT4
AM Frequency
Coverage
Adjustment
CT3
AM Tracking
Adjustment
CT1
FM Tracking
Adjustment
CT2
FM Frequency
Coverage
Adjustment
Set the CT2 (FM OSC) and CT4 (AM OSC)
trimmers to their extreme outside.
Inside NG Outside OK
Adjustment Location : MAIN board (Component side)
Adjustment Location : MAIN board (Conductor side)
