SECTION 8
ELECTRICAL PARTS LIST
CONTROL
BATTERY
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• Abbreviation
KR : Korea model
SP : Singapore model
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
* 1-639-678-12 CD MOTOR BOARD
***************
< CONNECTOR>
CNP707 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
< SWITCH >
S701 1-572-085-11 SWITCH, LEAF (LIMIT)
***********************************************************
* 1-673-259-11 CONNECTOR BOARD
****************
< CONNECTOR >
* CNP803 1-785-673-11 PIN, CONNECTOR (L) 7P
***********************************************************
* 1-672-304-11 CONTROL BOARD
**************
< SWITCH >
S801 1-762-798-11 SWITCH, KEYBOARD (MODE)
S802 1-762-798-11 SWITCH, KEYBOARD (DISPLAY/ENTER)
S803 1-762-798-11 SWITCH, KEYBOARD (PLAY)
S804 1-762-798-11 SWITCH, KEYBOARD (STOP)
S805 1-762-798-11 SWITCH, KEYBOARD (FR)
S806 1-762-798-11 SWITCH, KEYBOARD (FF)
***********************************************************
* 1-672-302-11 BATTERY BOARD
*************
3-028-154-01 TERMINAL (–), BATT
***********************************************************
* 1-672-358-11 HALF BATTERY BOARD
******************
3-028-154-01 TERMINAL (–), BATT
< CONNECTOR >
* CNP908 1-785-668-11 PIN, CONNECTOR (L) 2P
***********************************************************
* 1-672-301-11 POWER BOARD
************
< CAPACITOR >
C901 1-101-005-00 CERAMIC 0.022uF 50V
C902 1-101-005-00 CERAMIC 0.022uF 50V
C903 1-101-005-00 CERAMIC 0.022uF 50V
C904 1-101-005-00 CERAMIC 0.022uF 50V
< DIODE >
D901 8-719-063-79 DIODE 1N4002B
D902 8-719-063-79 DIODE 1N4002B
D903 8-719-063-79 DIODE 1N4002B
D904 8-719-063-79 DIODE 1N4002B
< FUSE >
! F902 1-532-286-11 FUSE ,TIME LAG (2.5A/250V)
< FUSE HOLDER >
FH901 1-533-233-31 HOLDER, FUSE
FH902 1-533-233-31 HOLDER, FUSE
< CABLE HOLDER >
* KH904 1-573-287-11 HOLDER, CABLE 2P
************************************************************
* 1-672-299-11 RECORD SWITCH BOARD
********************
< CONNECTOR >
* CNP302 1-785-656-11 PIN, CONNECTOR 4P
< SWITCH >
S301 1-762-565-11 SWITCH, SLIDE (REC/PB)
************************************************************
CONNECTOR
HALF BATTERY
POWER
RECORD SWITCH
CD MOTOR
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
