NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 26 —
SECTION 4
ELECTRICAL PARTS LIST
* 1-672-302-11 BATTERY BOARD
**************
3-028-154-01 TERMINAL (-), BATT
**************************************************************
1-639-678-12 CD MOTOR BOARD
****************
< CONNECTOR >
CNP707 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
< SWITCH >
* S701 1-572-085-11 SWITCH, LEAF (LINIT)
**************************************************************
1-676-124-11 CONNECTOR BOARD
*****************
< CONNECTOR >
* CNP803 1-785-669-11 PIN, CONNECTOR (PC BOARD) 3P
**************************************************************
* 1-676-119-11 CONTROL BOARD
***************
3-831-441-11 CUSHION (B)
< RESISTOR >
R801 1-249-419-11 CARBON 1.5K 5% 1/4W F
R802 1-247-843-11 CARBON 3.3K 5% 1/4W
R803 1-249-429-11 CARBON 10K 5% 1/4W
R804 1-249-419-11 CARBON 1.5K 5% 1/4W F
< SWITCH >
S801 1-762-798-11 SWITCH, KEYBOARD (MODE)
S802 1-762-798-11 SWITCH, KEYBOARD (DISPLAY/ENTER)
S803 1-762-798-11 SWITCH, KEYBOARD (PLAY)
S804 1-762-798-11 SWITCH, KEYBOARD (STOP)
S805 1-762-798-11 SWITCH, KEYBOARD (FR)
S806 1-762-798-11 SWITCH, KEYBOARD (FF)
**************************************************************
* 1-676-118-11 DISPLAY BOARD
**************
3-018-845-01 HOLDER (406), LCD
< CONNECTOR >
CNP801 1-695-380-31 PIN, CONNECTOR (PC BOARD) 19P
< LIQUID CRYSTAL DISPLAY >
LCD800 1-801-913-11 DISPLAY PANEL, LIQUID CRYSTAL
**************************************************************
* 1-672-358-11 HALF BATTERY BOARD
*******************
3-028-154-01 TERMINAL (-), BATT
< CONNECTOR >
* CNP908 1-785-668-11 PIN, CONNECTOR (PC BOARD) 2P
**************************************************************
* 1-676-116-11 INLET BOARD
***********
* CNP902 1-785-670-11 PIN, CONNECTOR (PC BOARD) 4P
* CNP907 1-785-655-11 PIN, CONNECTOR (PC BOARD) 3P
< FERRITE BEAD >
FB901 1-410-397-21 FERRITE BEAD INDUCTOR
< JACK >
0 J901 1-526-838-11 INLET, AC 2P (AC IN)
< HOLDER >
* KH901 1-573-287-11 HOLDER, CABLE 2P
< RESISTOR >
R901 1-249-421-11 CARBON 2.2K 5% 1/4W F
**************************************************************
* A-3321-916-A MAIN BOARD, COMPLETE
*********************
3-031-559-01 GEAR (PVC 2 BAND)
3-031-570-11 KNOB (FUNCTION)
7-621-775-20 SCREW +B 2.6X5
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
BATTERY CD MOTOR CONNECTOR CONTROL DISPLAY
HALF BATTERY INLET MAIN
