— 45 —
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
* 1-672-305-11 VOLUME BOARD
*************
< CABLE HOLDER >
* KH307 1-568-135-21 HOLDER, CABLE 7P
< RESISTOR >
R308 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV352 1-225-764-11 RES, VAR, CARBON (VOLUME)
< SWITCH >
S355 1-762-950-11 SWITCH, PUSH (1 KEY)(MEGA BASS)
************************************************************
* 1-672-303-11 DISPLAY BOARD
*************
3-018-845-01 HOLDER (406), LCD
< CONNECTOR >
CNP801 1-695-380-31 PIN, CONNECTOR (PC BOARD) 19P
< LIQUID CRYSTAL DISPLAY >
LCD800 1-801-913-11 DISPLAY PANEL, LIQUID CRYSTAL
************************************************************
* 1-672-300-11 INLET BOARD
***********
< CONNECTOR >
* CNP902 1-785-670-11 PIN, CONNECTOR (L) 4P
* CNP907 1-785-655-11 PIN, CONNECTOR 3P
< JACK >
J901 1-526-838-11 INLET, AC 2P
< CABLE HOLDER >
* KH901 1-573-287-11 HOLDER, CABLE 2P
< RESISTOR >
R901 1-249-421-11 CARBON 2.2K 5% 1/4W F
***********************************************************
* A-3321-916-A MAIN BOARD, COMPLETE
********************
7-621-775-20 SCREW +B 2.6 × 5
7-685-647-79 SCREW +BVTP 3 × 10 TYPE2 N-S
< CAPACITOR >
C1 1-162-215-31 CERAMIC 47PF 5% 50V
C2 1-162-306-11 CERAMIC 0.01uF 20% 16V
C3 1-104-664-11 ELECT 47uF 20% 10V
C5 1-162-205-31 CERAMIC 18PF 5% 50V
C6 1-102-962-00 CERAMIC 30PF 5% 50V
C7 1-162-196-31 CERAMIC 5.6PF 10% 50V
C8 1-162-191-31 CERAMIC 2.2PF 10% 50V
C9 1-162-306-11 CERAMIC 0.01uF 20% 16V
C11 1-126-963-11 ELECT 4.7uF 20% 50V
C12 1-124-903-11 ELECT 1uF 20% 50V
C13 1-104-664-11 ELECT 47uF 20% 10V
C14 1-104-664-11 ELECT 47uF 20% 10V
C15 1-162-306-11 CERAMIC 0.01uF 20% 16V
C16 1-126-961-11 ELECT 2.2uF 20% 50V
C17 1-104-664-11 ELECT 47uF 20% 10V
C18 1-127-876-21 CERAMIC 0.01uF 10% 50V
C19 1-127-876-21 CERAMIC 0.01uF 10% 50V
C20 1-162-306-11 CERAMIC 0.01uF 20% 16V
C21 1-162-205-31 CERAMIC 18PF 5% 50V
C22 1-124-903-11 ELECT 1uF 20% 50V
C23 1-124-902-00 ELECT 0.47uF 20% 50V
C24 1-126-963-11 ELECT 4.7uF 20% 50V
C26 1-162-294-31 CERAMIC 0.001uF 10% 50V
C28 1-162-306-11 CERAMIC 0.01uF 20% 16V
C101 1-162-301-11 CERAMIC 0.0015uF 20% 16V
C102 1-104-664-11 ELECT 47uF 20% 10V
C103 1-127-883-21 CERAMIC 0.039uF 10% 50V
C104 1-162-302-11 CERAMIC 0.0022uF 0% 16V
C105 1-162-215-31 CERAMIC 47PF 5% 50V
C108 1-124-902-00 ELECT 0.47uF 20% 50V
C109 1-124-903-11 ELECT 1uF 20% 50V
C121 1-124-903-11 ELECT 1uF 20% 50V
C122 1-127-885-21 CERAMIC 0.056uF 10% 50V
C140 1-124-252-00 ELECT 0.33uF 20% 50V
C151 1-104-664-11 ELECT 47uF 20% 10V
C152 1-162-290-31 CERAMIC 470PF 10% 50V
C153 1-124-443-00 ELECT 100uF 20% 10V
C154 1-124-473-11 ELECT 1000uF 20% 10V
C155 1-136-165-00 FILM 0.1uF 5% 50V
C157 1-127-883-21 CERAMIC 0.039uF 10% 50V
C158 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C201 1-162-301-11 CERAMIC 0.0015uF 20% 16V
C202 1-104-664-11 ELECT 47uF 20% 10V
C203 1-127-883-21 CERAMIC 0.039uF 10% 50V
C204 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C205 1-162-215-31 CERAMIC 47PF 5% 50V
C208 1-124-902-00 ELECT 0.47uF 20% 50V
C209 1-124-903-11 ELECT 1uF 20% 50V
C221 1-124-903-11 ELECT 1uF 20% 50V
C222 1-127-885-21 CERAMIC 0.056uF 10% 50V
INLET
MAIN
VOLUME DISPLAY
