— 27 —
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
TUNER
TRANSLATION(HEAD)
1-670-207-11 TRANSLATION (HEAD) BOARD
************************
************************************************************
* A-3321-465-A TUNERBOARD, COMPLETE (E,SP)
* A-3321-471-A TUNERBOARD, COMPLETE (EA)
*************************
< CAPACITOR >
C1 1-162-286-31 CERAMIC 220PF 10% 50V
C2 1-162-215-31 CERAMIC 47PF 5% 50V
C3 1-162-306-11 CERAMIC 0.01uF 30% 16V
C4 1-104-664-11 ELECT 47uF 20% 10V
C5 1-162-294-31 CERAMIC 0.001uF 10% 50V
C6 1-162-204-31 CERAMIC 16PF 5% 50V
(E,SP)
C6 1-162-207-31 CERAMIC 22PF 5% 50V (EA)
C8 1-102-959-00 CERAMIC 22PF 5% 50V
(E,SP)
C8 1-102-961-00 CERAMIC 27PF 5% 50V (EA)
C10 1-162-193-31 CERAMIC 3.3PF 10% 50V
C11 1-162-306-11 CERAMIC 0.01uF 30% 16V
C14 1-162-282-31 CERAMIC 100PF 10% 50V
C15 1-126-963-11 ELECT 4.7uF 20% 50V
C16 1-124-903-11 ELECT 1uF 20% 50V
C17 1-124-907-11 ELECT 10uF 20% 50V
C18 1-124-907-11 ELECT 10uF 20% 50V
C19 1-162-306-11 CERAMIC 0.01uF 30% 16V
C20 1-124-903-11 ELECT 1uF 20% 50V
C21 1-126-961-11 ELECT 2.2uF 20% 50V
C22 1-124-443-00 ELECT 100uF 20% 10V
C23 1-124-902-00 ELECT 0.47uF 20% 50V
C24 1-126-963-11 ELECT 4.7uF 20% 50V
C25 1-126-956-91 ELECT 0.1uF 20% 50V
C26 1-162-203-31 CERAMIC 15PF 5% 50V
C27 1-161-050-00 CERAMIC 0.0082uF 10% 16V
C28 1-161-050-00 CERAMIC 0.0082uF 10% 16V
C29 1-162-282-31 CERAMIC 100PF 10% 50V
C30 1-162-282-31 CERAMIC 100PF 10% 50V
C32 1-162-198-31 CERAMIC 8.2PF 10% 50V
C35 1-162-282-31 CERAMIC 100PF 10% 50V
C36 1-164-617-11 CERAMIC 4PF 5% 50V
C38 1-162-203-31 CERAMIC 15PF 5% 50V
(E,SP)
C38 1-162-205-31 CERAMIC 18PF 5% 50V (EA)
C39 1-164-617-11 CERAMIC 4PF 5% 50V
C40 1-136-480-11 FILM 0.0015uF 5% 100V
C41 1-107-734-11 FILM 360PF 5% 100V
C42 1-136-683-11 FILM 0.0056uF 5% 100V
C46 1-162-282-31 CERAMIC 100PF 10% 50V
C47 1-162-282-31 CERAMIC 100PF 10% 50V
C50 1-162-282-31 CERAMIC 100PF 10% 50V
C51 1-162-294-31 CERAMIC 0.001uF 10% 50V
C52 1-162-202-31 CERAMIC 13PF 5% 50V
C53 1-162-287-31 CERAMIC 270PF 10% 50V
C71 1-162-306-11 CERAMIC 0.01uF 30% 16V
< FILTER >
CF1 1-760-738-61 FILTER, CERAMIC
CF2 1-567-670-11 FILTER, CERAMIC
< CONNECTOR >
CN1 1-506-987-11 PIN, CONNECTOR (PC BOARD) 5P
< TRIMMER >
CT6 1-141-485-11 CAP, ADJ 5PF
CT8 1-141-485-11 CAP, ADJ 5PF
< VARIABLE CAPACITOR >
CT1-4 1-151-693-1 CAP, VAR (TUNE)
CV1-4 1-151-693-1 CAP, VAR (TUNE)
< DIODE >
D1 8-719-911-19 DIODE 1SS119
D2 8-719-911-19 DIODE 1SS119
D3 8-719-911-19 DIODE 1SS119
< IC >
IC1 8-752-050-20 IC CXA1238S
< COIL >
L1 1-406-998-11 COIL, AIR-CORE (E,SP)
L1 1-406-999-11 COIL, AIR-CORE (EA)
L2 1-422-230-11 COIL, AIR-CORE (E,SP)
L2 1-406-957-21 COIL(WITH CORE) (EA)
L3 1-754-000-21 ANTENNA, FERRITE-ROD (MW)
L4 1-406-470-11 COIL(OSC)
L5 1-402-597-31 COIL(ANT)
L6 1-406-247-11 COIL(OSC)
L7 1-402-595-31 COIL(ANT)
L8 1-406-253-11 COIL(OSC)
L9 1-410-750-41 INDUCTOR 0.47uH
L12 1-410-750-41 INDUCTOR 0.47uH
< TRANSISTOR >
Q1 8-729-036-77 TRANSISTOR KRC107M
Q2 8-729-036-89 TRANSISTOR KTC3198GR-AT
< RESISTOR >
R1 1-249-429-11 CARBON 10K 5% 1/4W
R3 1-249-421-11 CARBON 2.2K 5% 1/4W F
R6 1-249-441-11 CARBON 100K 5% 1/4W
R9 1-249-441-11 CARBON 100K 5% 1/4W
R10 1-249-397-11 CARBON 22 5% 1/4W F
R11 1-249-427-11 CARBON 6.8K 5% 1/4W F
R12 1-249-427-11 CARBON 6.8K 5% 1/4W F
R14 1-249-429-11 CARBON 10K 5% 1/4W
R15 1-247-887-00 CARBON 220K 5% 1/4W
R16 1-247-887-00 CARBON 220K 5% 1/4W
R17 1-249-421-11 CARBON 2.2K 5% 1/4W F
R21 1-249-409-11 CARBON 220 5% 1/4W F
R30 1-249-417-11 CARBON 1K 5% 1/4W F
R31 1-247-854-11 CARBON 9.1K 5% 1/4W
R32 1-249-441-11 CARBON 100K 5% 1/4W
R33 1-249-415-11 CARBON 680 5% 1/4W F
