TUNER
Ref. No. Part No. Description Remarks
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
< VARIABLE RESISTOR >
RV1 1-228-995-00 RES, ADJ, METAL22K
RV2 1-225-637-11 RES, VAR, CARBON 100 (FINE TUNE)
< SWITCH >
S1 1-571-147-11 SWITCH, LEVER SLIDE (BAND)
< TRANSFORMER >
T1 1-409-944-11 COIL(DET)
T2 1-406-952-11 TRANSFORMER, IF
************************************************************
MISCELLANEOUS
**************
ANT1 1-501-918-11 ANTENNA, TELESCOPIC
! F901 1-532-149-31 FUSE,0.125A 250V
HE901 1-500-338-11 HEAD, MAGNETIC (ERASE)
HRP901 1-543-872-11 HEAD, MAGNETIC (REC/PB)
S901 1-692-302-11 SWITCH, LEAF (POWER)
S902 1-571-556-11 SWITCH, LEAF (DIRECTION)
SP901 1-505-955-11 SPEAKER (10cm)
SP902 1-505-955-11 SPEAKER (10cm)
! T901 1-431-916-11 TRANSFORMER, POWER
************************************************************
ACCESSORIES & PACKING MATERIALS
*****************************
! 1-569-008-21 ADAPTOR, CONVERSION (2P)(EA)
! 1-769-412-13 CORD,POWER
3-865-191-11 MANUAL, INSTRUCTION (ENGLISH)
3-865-191-21 MANUAL, INSTRUCTION (FRENCH/SPANISH)
(E,SP)
3-865-191-41 MANUAL, INSTRUCTION (ARABIC)(EA)
************************************************************
*************
HARDWARE LIST
*************
#1 7-685-647-79 SCREW +BVTP 3 × 10 TYPE2 N-S
#2 7-685-648-79 SCREW +BVTP 3 × 12 TYPE2 N-S
#3 7-685-650-79 SCREW +BVTP 3 × 16 TYPE2 N-S
#4 7-685-533-14 SCREW +BTP 2.6 × 6 TYPE2 N-S
#5 7-685-532-19 SCREW +BTP 2.6 × 5 TYPE2 N-S
#6 7-682-548-09 SCREW +B 3 × 8
#7 7-621-772-10 SCREW +B 2 × 4
#8 7-685-851-04 SCREW +BVTT 2 × 4
#9 7-621-770-67 SCREW +B 2.6 × 6
#10 7-685-248-19 SCREW +KTP 3 × 12 TYPE2 NON-SLIT
