Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
43
HCD-DC1
CD HEADPHONE I/O SWITCH LCD LOADING MOTOR MAIN
R118 1-216-809-11 METAL CHIP 100 5% 1/16W
R119 1-216-817-11 METAL CHIP 470 5% 1/16W
R123 1-216-833-11 METAL CHIP 10K 5% 1/16W
R124 1-216-845-11 METAL CHIP 100K 5% 1/16W
R131 1-216-809-11 METAL CHIP 100 5% 1/16W
R132 1-216-863-11 RES-CHIP 3.3M 5% 1/16W
R143 1-216-848-11 METAL CHIP 180K 5% 1/16W
R144 1-216-848-11 METAL CHIP 180K 5% 1/16W
R147 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R148 1-216-797-11 METAL CHIP 10 5% 1/16W
R149 1-216-797-11 METAL CHIP 10 5% 1/16W
R158 1-216-852-11 METAL CHIP 390K 5% 1/16W
R159 1-216-847-11 METAL CHIP 150K 5% 1/16W
R160 1-216-833-11 METAL CHIP 10K 5% 1/16W
R161 1-216-821-11 METAL CHIP 1K 5% 1/16W
R162 1-216-847-11 METAL CHIP 150K 5% 1/16W
R171 1-218-291-11 RES-CHIP 16K 5% 1/16W
R172 1-216-833-11 METAL CHIP 10K 5% 1/16W
R173 1-216-835-11 METAL CHIP 15K 5% 1/16W
R181 1-218-291-11 RES-CHIP 16K 5% 1/16W
R182 1-216-833-11 METAL CHIP 10K 5% 1/16W
R183 1-216-835-11 METAL CHIP 15K 5% 1/16W
< NETWORK RESISTOR >
RN101 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT)
< VIBRATOR >
X101 1-781-947-11 VIBRATOR, CRYSTAL (16.9344MHz)
**************************************************************
1-682-409-11 HEADPHONE BOARD
*****************
< CAPACITOR >
C161 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C261 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
< FERRITE BEAD/RESISTOR >
FB301 1-414-813-11 FERRITE
FB303 1-414-813-11 FERRITE (CND, US)
FB303 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT CND, US)
FB304 1-414-813-11 FERRITE (CND, US)
FB304 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT CND, US)
FB305 1-414-813-11 FERRITE (CND, US)
FB305 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT CND, US)
< JACK >
J301 1-794-453-11 JACK (PHONES)
< COIL >
L102 1-412-002-31 INDUCTOR 4.7uH
L202 1-412-002-31 INDUCTOR 4.7uH
**************************************************************
1-682-417-11 I/O SWITCH BOARD
****************
< SWITCH >
S801 1-786-220-11 SWITCH, KEY BOARD (I/1)
**************************************************************
1-682-412-11 LCD BOARD
**********
< CONNECTOR >
CN803 1-785-949-11 CONNECTOR, FFC/FPC 20P
CN810 1-785-950-11 CONNECTOR, FFC/FPC 18P
< LED >
D866 8-719-085-55 LED SY3318-V-L (LCD BACK LIGHT)
D867 8-719-085-55 LED SY3318-V-L (LCD BACK LIGHT)
D868 8-719-085-55 LED SY3318-V-L (LCD BACK LIGHT)
D869 8-719-085-55 LED SY3318-V-L (LCD BACK LIGHT)
< LIQUID CRYSTAL DISPLAY >
LCD801 1-803-542-11 DISPLAY PANEL, LIQUID CRYSTAL
**************************************************************
1-681-807-11 LOADING MOTOR BOARD
*********************
< CONNECTOR >
* CN1 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S1 1-771-799-11 SWITCH, LEVER (SLIDE)
(DISC TRAY OPEN/CLOSE DETECT)
**************************************************************
A-4726-691-A MAIN BOARD, COMPLETE (AEP, UK)
A-4727-415-A MAIN BOARD, COMPLETE (HK, MY, SP)
A-4727-417-A MAIN BOARD, COMPLETE (CND, US)
A-4727-598-A MAIN BOARD, COMPLETE (MX)
*********************
4-217-354-11 BUSHING, INSULATING
4-230-078-01 SCREW, +BV TAPPING
7-685-546-14 SCREW +BTP 3X8 TYPE2 N-S
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C101 1-126-963-11 ELECT 4.7uF 20% 50V
C102 1-126-963-11 ELECT 4.7uF 20% 50V
C103 1-126-963-11 ELECT 4.7uF 20% 50V
C104 1-126-963-11 ELECT 4.7uF 20% 50V
C105 1-126-963-11 ELECT 4.7uF 20% 50V
C107 1-126-963-11 ELECT 4.7uF 20% 50V
C108 1-126-963-11 ELECT 4.7uF 20% 50V
