Sony CX-LEM200 - Cassette Door Assy; POWER Board, MAIN Board

10
CX-LEM200
3-6. Cassette Door Assy
3-7. POWER Board, MAIN Board
1 Open the cassette door assy.
3 cassette door assy
cla
w
2
1 connector
(AC IN)
2 connector
(CN901)
5 two screws
(+BVTP3
× 10)
3 four screws
(+BVTP4
× 12)
6 MAIN board
4 POWER boar
d
