SECTION 8
ELECTRICAL PARTS LIST
2
CX-LEM200
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
• Abbreviation
AUS : Australian model.
CND : Canadian model.
SP : Singapore model.
MY : Malaysia model.
TW : Taiwan model.
KR : Korean model.
E51 : Chilean and Peruvian models.
MX : Mexican model.
A-4732-685-A CONTROL BOARD, COMPLETE (CND,E51,MX)
A-4748-589-A CONTROL BOARD, COMPLETE (AUS,SP,MY,TW)
A-4748-592-A CONTROL BOARD, COMPLETE (KR)
***********************
< CAPACITOR >
C801 1-164-160-11 CERAMIC CHIP 20PF 5.00% 50V
(CND,E51,MX)
C801 1-162-975-11 CERAMIC CHIP 24PF 5.00% 50V
(EXCEPT CND,E51,MX)
C802 1-164-160-11 CERAMIC CHIP 20PF 5.00% 50V
(CND,E51,MX)
C802 1-162-975-11 CERAMIC CHIP 24PF 5.00% 50V
(EXCEPT CND,E51,MX)
C804 1-124-584-00 ELECT 100uF 20% 10V
(CND,E51,MX)
C804 1-126-382-11 ELECT 100uF 20.00% 6.3V
(EXCEPT CND,E51,MX)
C805 1-126-153-11 ELECT 22uF 20% 6.3V
(CND,E51,MX)
C805 1-126-514-11 ELECT 22uF 20.00% 16V
(EXCEPT CND,E51,MX)
C808 1-124-584-00 ELECT 100uF 20% 10V
(CND,E51,MX)
C808 1-126-382-11 ELECT 100uF 20.00% 6.3V
(EXCEPT CND,E51,MX)
C812 1-124-584-00 ELECT 100uF 20% 10V
(CND,E51,MX)
C812 1-126-382-11 ELECT 100uF 20.00% 6.3V
(EXCEPT CND,E51,MX)
C814 1-124-584-00 ELECT 100uF 20% 10V
(CND,E51,MX)
C814 1-126-382-11 ELECT 100uF 20.00% 6.3V
(EXCEPT CND,E51,MX)
C815 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(CND,E51,MX)
C815 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
(EXCEPT CND,E51,MX)
C818 1-115-871-11 ELECT 1uF 20.00% 50V
(EXCEPT CND,E51,MX)
C819 1-126-160-11 ELECT 1uF 20% 50V
(CND,E51,MX)
C819 1-115-871-11 ELECT 1uF 20.00% 50V
(EXCEPT CND,E51,MX)
C822 1-126-153-11 ELECT 22uF 20% 6.3V
(CND,E51,MX)
C822 1-126-514-11 ELECT 22uF 20.00% 16V
(EXCEPT CND,E51,MX)
C829 1-124-589-11 ELECT 47uF 20% 16V
(CND,E51,MX)
C829 1-113-340-11 ELECT 47uF 20.00% 25V
(EXCEPT CND,E51,MX)
C830 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(CND,E51,MX)
C830 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
(EXCEPT CND,E51,MX)
C831 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(CND,E51,MX)
C831 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
(EXCEPT CND,E51,MX)
C834 1-124-259-11 ELECT 4.7uF 20.00% 16V
(CND,E51,MX)
C834 1-126-794-11 ELECT 4.7uF 20.00% 50V
(EXCEPT CND,E51,MX)
C835 1-124-259-11 ELECT 4.7uF 20.00% 16V
(CND,E51,MX)
C835 1-126-794-11 ELECT 4.7uF 20.00% 50V
(EXCEPT CND,E51,MX)
C839 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
(EXCEPT CND,E51,MX)
C840 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
(EXCEPT CND,E51,MX)
C841 1-127-888-21 CERAMIC 0.1uF 10% 50V
(EXCEPT CND,E51,MX)
< DIODE >
D811 8-719-075-50 DIODE SELS6B14C-TP5 (CND,E51,MX)
D811 8-719-060-44 DIODE SLR-342VRT32 (EXCEPT CND,E51,MX)
D812 8-719-991-33 DIODE 1SS133T-77 (EXCEPT CND,E51,MX)
D813 8-719-991-33 DIODE 1SS133T-77 (EXCEPT CND,E51,MX)
< IC >
IC802 8-759-827-70 IC NJL64H400A-1 (CND,E51,MX)
IC802 6-702-906-01 IC NJL64H380A (EXCEPT CND,E51,MX)
< RESISTOR >
R801 1-216-821-11 METAL CHIP 1K 5% 1/10W
(CND,E51,MX)
R801 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EXCEPT CND,E51,MX)
R802 1-216-821-11 METAL CHIP 1K 5% 1/10W
(CND,E51,MX)
R802 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EXCEPT CND,E51,MX)
R811 1-249-433-11 CARBON 22K 5% 1/4W
(CND,E51,MX)
R811 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT CND,E51,MX)
R812 1-249-417-11 CARBON 1K 5% 1/4W F
(CND,E51,MX)
R812 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EXCEPT CND,E51,MX)
R814 1-216-845-11 METAL CHIP 100K 5% 1/10W
(CND,E51,MX)
CONTROL
Ver 1.1 2003.06
