3
CX-LEM200
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R814 1-216-852-11 METAL CHIP 390K 5% 1/10W
(EXCEPT CND,E51,MX)
R817 1-249-417-11 CARBON 1K 5% 1/4W F
(CND,E51,MX)
R821 1-216-845-11 METAL CHIP 100K 5% 1/10W
(CND,E51,MX)
R821 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EXCEPT CND,E51,MX)
R826 1-216-821-11 METAL CHIP 1K 5% 1/10W
(CND,E51,MX)
R826 1-216-864-11 METAL CHIP 0 5% 1/10W
(EXCEPT CND,E51,MX)
R828 1-249-417-11 CARBON 1K 5% 1/4W F
(CND,E51,MX)
R828 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EXCEPT CND,E51,MX)
R829 1-249-417-11 CARBON 1K 5% 1/4W F
(CND,E51,MX)
R829 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EXCEPT CND,E51,MX)
R835 1-249-417-11 CARBON 1K 5% 1/4W F
(CND,E51,MX)
R835 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EXCEPT CND,E51,MX)
R836 1-249-417-11 CARBON 1K 5% 1/4W F
(CND,E51,MX)
R836 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EXCEPT CND,E51,MX)
R849 1-249-421-11 CARBON 2.2K 5% 1/4W F
(CND,E51,MX)
R849 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(EXCEPT CND,E51,MX)
R862 1-216-864-11 METAL CHIP 0 5% 1/10W
(CND,E51,MX)
R867 1-216-841-11 METAL CHIP 47K 5% 1/10W
(EXCEPT CND,E51,MX)
R868 1-216-864-11 METAL CHIP 0 5% 1/10W
(CND,E51,MX)
R868 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(KR)
R868 1-216-841-11 METAL CHIP 47K 5% 1/10W
(AUS,SP,MY,TW)
R875 1-216-809-11 METAL CHIP 100 5% 1/10W
(CND,E51,MX)
R875 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EXCEPT CND,E51,MX)
R876 1-216-833-11 METAL CHIP 10K 5% 1/10W
(CND,E51,MX)
R876 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EXCEPT CND,E51,MX)
R892 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EXCEPT CND,E51,MX)
R898 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(CND,E51,MX)
**************************************************************
A-4732-682-A MAIN BOARD, COMPLETE (EXCEPT CND)
A-4732-687-A MAIN BOARD, COMPLETE (CND)
********************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S (CND)
< CAPACITOR >
C104 1-128-551-11 ELECT 22uF 20.00% 25V
(CND)
C104 1-126-947-11 ELECT 47uF 20.00% 10V
(EXCEPT CND)
C127 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(CND)
C127 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
(EXCEPT CND)
C134 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(EXCEPT CND)
C204 1-128-551-11 ELECT 22uF 20.00% 25V
(CND)
C204 1-126-947-11 ELECT 47uF 20.00% 10V
(EXCEPT CND)
C227 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(CND)
C227 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
(EXCEPT CND)
C234 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(EXCEPT CND)
C316 1-130-475-00 MYLAR 0.0022uF 5% 50V
(CND)
C316 1-130-481-00 MYLAR 0.0068uF 5% 50V
(EXCEPT CND)
C317 1-130-483-00 MYLAR 0.01uF 5% 50V
(CND)
C317 1-130-471-00 MYLAR 0.001uF 5% 50V
(EXCEPT CND)
C318 1-130-473-00 MYLAR 0.0015uF 5% 50V
(CND)
C318 1-130-483-00 MYLAR 0.01uF 5% 50V
(EXCEPT CND)
C330 1-126-935-11 ELECT 470uF 20.00% 10V
(CND)
C330 1-126-934-11 ELECT 220uF 20.00% 10V
(EXCEPT CND)
C347 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT CND)
C348 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT CND)
C349 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT CND)
C350 1-127-884-21 CERAMIC 0.047uF 10% 50V
(EXCEPT CND)
< CONNECTOR >
CN304 1-784-772-71 CONNECTOR, FFC 11P (CND)
CN304 1-568-830-11 CONNECTOR, FFC 11P (EXCEPT CND)
< RESISTOR >
R101 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
(CND)
R101 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(EXCEPT CND)
R105 1-216-852-11 METAL CHIP 390K 5% 1/10W
(EXCEPT CND)
R128 1-216-821-11 METAL CHIP 1K 5% 1/10W
(CND)
R128 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(EXCEPT CND)
MAINCONTROL
Ver 1.1 2003.06
