4
CX-LEM200
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R131 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(CND)
R131 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(EXCEPT CND)
R132 1-216-821-11 METAL CHIP 1K 5% 1/10W
R201 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
(CND)
R201 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(EXCEPT CND)
R205 1-216-852-11 METAL CHIP 390K 5% 1/10W
(EXCEPT CND)
R228 1-216-821-11 METAL CHIP 1K 5% 1/10W
(CND)
R228 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(EXCEPT CND)
R231 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(CND)
R231 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(EXCEPT CND)
R232 1-216-821-11 METAL CHIP 1K 5% 1/10W
R309 1-216-864-11 METAL CHIP 0 5% 1/10W
(CND)
R309 1-249-389-11 CARBON 4.7 5% 1/4W F
(EXCEPT CND)
R311 1-216-833-11 METAL CHIP 10K 5% 1/10W
(CND)
R311 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT CND)
R327 1-216-864-11 METAL CHIP 0 5% 1/10W
(CND)
R327 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EXCEPT CND)
R343 1-249-385-11 CARBON 2.2 5% 1/6W F
(CND)
R343 1-249-387-11 CARBON 3.3 5% 1/4W F
(EXCEPT CND)
R344 1-249-385-11 CARBON 2.2 5% 1/6W F
(CND)
R344 1-249-387-11 CARBON 3.3 5% 1/4W F
(EXCEPT CND)
R345 1-249-385-11 CARBON 2.2 5% 1/6W F
(CND)
R345 1-249-387-11 CARBON 3.3 5% 1/4W F
(EXCEPT CND)
R346 1-249-385-11 CARBON 2.2 5% 1/6W F
(CND)
R346 1-249-387-11 CARBON 3.3 5% 1/4W F
(EXCEPT CND)
R353 1-249-389-11 CARBON 4.7 5% 1/4W F
(CND)
**************************************************************
1-688-197-11 POWER BOARD
*************
< CAPACITOR >
C905 1-164-097-11 CERAMIC 0.022uF 50V (CND)
C905 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT CND)
C906 1-164-097-11 CERAMIC 0.022uF 50V (CND)
C906 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT CND)
C907 1-164-097-11 CERAMIC 0.022uF 50V (CND)
C907 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT CND)
C908 1-164-097-11 CERAMIC 0.022uF 50V (CND)
C908 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT CND)
C909 1-164-097-11 CERAMIC 0.022uF 50V (CND)
C909 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT CND)
C910 1-164-097-11 CERAMIC 0.022uF 50V (CND)
C910 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT CND)
C911 1-164-097-11 CERAMIC 0.022uF 50V (CND)
C911 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT CND)
C912 1-164-097-11 CERAMIC 0.022uF 50V (CND)
C912 1-101-005-00 CERAMIC 22000PF 50V
(E51,AUS,SP,MY,TW,KR)
C913 1-164-097-11 CERAMIC 0.022uF 50V (CND)
C913 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT CND)
C914 1-164-097-11 CERAMIC 0.022uF 50V (CND)
C914 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT CND)
C915 1-164-097-11 CERAMIC 0.022uF 50V (CND)
C915 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT CND)
C916 1-164-097-11 CERAMIC 0.022uF 50V (CND)
C916 1-101-005-00 CERAMIC 22000PF 50V
(EXCEPT CND)
< CONNECTOR >
* CN902 1-691-756-11 PIN, CONNECTOR (PC BOARD) 2P (CND)
* CN902 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
(EXCEPT CND)
< DIODE >
D916 8-719-902-17 DIODE 1N5401 (CND)
D916 8-719-046-47 DIODE 1N5401M (EXCEPT CND)
D917 8-719-902-17 DIODE 1N5401 (CND)
D917 8-719-046-47 DIODE 1N5401M (EXCEPT CND)
D918 8-719-902-17 DIODE 1N5401 (CND)
D918 8-719-046-47 DIODE 1N5401M (EXCEPT CND)
D919 8-719-902-17 DIODE 1N5401 (CND)
D919 8-719-046-47 DIODE 1N5401M (EXCEPT CND)
D921 8-719-063-79 DIODE 1N4002B (CND,MX)
D925 8-719-063-79 DIODE 1N4002B
< RESISTOR >
R907 1-247-807-31 CARBON 100 5% 1/4W
(CND,MX)
0 R907 1-212-881-11 FUSIBLE 100 5% 1/4W
(E51,AUS,SP,MY,TW,KR)
0 R911 1-219-237-51 CARBON 3.3M 5% 1/2W
(CND)
< RELAY >
0 RY901 1-755-276-11 RELAY, POWER (AUS,TW,KR)
MAIN POWER
Ver 1.1 2003.06
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
