Sony CX-LEM200 - Page 27

27
CX-LEM200
REC-O_L
REC-O_R
TUNER-R TUNER-L
CD-L
AUX-L
OUT-L
OUT-R
TON_L-L TON_L-R
AUX-R CD-R
VSS
TON_H-R TON_H-L
TAPE-L
TAPE-R
IC302 BD3881FV
– MAIN Board –
IC303 LA4636
1
RIPPLE FILTER/
STARTING TIME
2
IN1
3
PRE GND
4
IN2
5
STAND BY
SIGNAL MUTE
6
VCC
7 8
–OUT2 +OUT2
9
PWR GND2
10
+OUT1 –OUT1
11 12
+
–
+
–
INPUT
AMP
INPUT
AMP
OUTPUT
AMP
OUTPUT
AMP
