29
CX-LEM200
Pin No.
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
I/O
O
O
O
O
—
—
I
I
I
I
O
I
O
O
I
O
Pin Name
C-XRST
C-XLT
C-DATA
C-SQCK
GND
VDD2
RDS-DATA
TU STEREO
TU TUNED
C-SENS
C-LDON
C-SQSO
C-CLK
TU DATA
TU COUNT
TU CLK
Description
Reset signal output to the CD unit
Latch signal output to the CD unit
Data output to the CD unit
SUBQ clock output to the CD unit
Ground terminal
Power supply terminal
RDS data input from the tuner
Stereo/mono detection signal input from the tuner
Tuner tuned status signal input
SENS signal input from the CD unit
LD ON signal output to the CD unit
SUB-Q data input from the CD unit
Clock output to the CD unit
Data output to the tuner
IF count signal input from the tuner
Clock signal output to the tuner
