40
CX-LEM200
Ref. No. Part No. Description Remarks
< DIODE >
D906 8-719-991-33 DIODE 1SS133T-77
D907 8-719-063-79 DIODE 1N4002B
D908 8-719-063-79 DIODE 1N4002B
D909 8-719-063-79 DIODE 1N4002B
D910 8-719-063-79 DIODE 1N4002B
D911 8-719-063-79 DIODE 1N4002B
D912 8-719-063-79 DIODE 1N4002B
D913 8-719-063-79 DIODE 1N4002B
D914 8-719-063-79 DIODE 1N4002B
D916 8-719-902-17 DIODE 1N5401
D917 8-719-902-17 DIODE 1N5401
D918 8-719-902-17 DIODE 1N5401
D919 8-719-902-17 DIODE 1N5401
D920 8-719-991-33 DIODE 1SS133T-77
D921 8-719-991-33 DIODE 1SS133T-77
D922 8-719-063-79 DIODE 1N4002B
D923 8-719-063-79 DIODE 1N4002B
D924 8-719-063-79 DIODE 1N4002B
D925 8-719-063-79 DIODE 1N4002B
< LINE FILTER >
0LF901 1-402-663-11 TRANSFORMER, LINE FILTER (LFT)
< RESISTOR >
R901 1-249-437-11 CARBON 47K 5% 1/4W
R902 1-249-437-11 CARBON 47K 5% 1/4W
R907 1-247-807-31 CARBON 100 5% 1/4W
0R911 1-219-237-51 CARBON 3.3M 5% 1/2W
(US)
< RELAY >
0RY901 1-755-276-11 RELAY
< TRANSFORMER >
0T901 1-439-781-11 TRANSFORMER, POWER (US)
0T901 1-439-779-11 TRANSFORMER, POWER (AEP,UK)
************************************************************
REGULATOR BOARD
*****************
< IC >
IC305 8-759-347-18 IC KIA7809API
************************************************************
MISCELLANEOUS
***************
08 1-696-169-12 CORD, POWER (AEP,UK)
08 1-783-531-81 CORD, POWER (US)
10 1-693-619-11 TUNER (FM/AM)
106 1-757-055-11 WIRE, PARALLEL (FFC) (16 CORE)
S800 1-692-960-11 SWITCH, PUSH (1 KEY) (OPEN)
0T902 1-439-784-11 TRANSFORMER, POWER (AEP,UK)
0T902 1-439-785-11 TRANSFORMER, POWER (US)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
POWER REGULATOR
