40
CX-LFA660/LFA770
Pin No. Pin Name I/O Description
72 VDD4 — Power supply terminal
73 TU-CE O Tuner chip enable signal output to the tuner
74 TU-CLOCK O Tuner clock signal output
75 TU-DI I Tuner data input
76 TU- DO O Tuner data output
77 TU-MUTE O Muting signal output to the tuner
78 TA-MOTOR O Motor control signal output to the tape deck
79 TA-R/P O REC/PLAY coutrol signal output to the REC/PLAY switch circuit
80 TA-BIAS O Bias control signal output to the bias oscillation circuit
81 TA- SOL O Solenoid control signal output to the tape deck
82 AMP ST-BY — Not used
83 AMP MUTE — Not used
84 NC — Not used
85 POWER ON O Power relay control signal output
86 O-MUTE O Muting control signal output to the power amplifier
87 STD-BY LED O Standby LED control signal output
88 NC/DSGX/I-BASS LED — Not used
89 GND — Ground terminal
90 VDD2 — Power supply terminal
91 O-TRY-OPN O CD tray open control signal output
92 O-TRY-CLS O CD tray close control signal output
93 O-TA-LED — Not used
94 CD POWER O CD power control signal output
95 O-CD-DATA O Data output to the CD unit
96 I-CD-SENS I SENS signal input from the CD unit
97 O-CD-CLK O Clock output to the CD unit
98 MI-DIO-O O MIDIO signal output to the CD unit
99 MI-DIO-I I MIDIO signal input to the CD unit
100 MI-CK O MICK signal output to the CD unit
